Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-1.

Typically the A-weighted sound pressure level of the product
is 74 dB(A). Uncertainty K = 3 dB.
The noise level when working can exceed 80 dB(A).

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745-2-1:

Drilling into metal: a

h

= 2.5 m/s

2

, K = 1.5 m/s

2

Impact drilling into concrete: a

h

= 17 m/s

2

, K = 2.0 m/s

2

Screwdriving without impact: a

h

= 2.5 m/s

2

, K = 1.5 m/s

2

.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2009/125/EC (Regulation
1194/2012), 2011/65/EU, until 19 April 2016:
2004/108/EC, from 20 April 2016 on: 2014/30/EU,
2006/42/EC including their amendments and complies with
the following standards: EN 60745-1, EN 60745-2-1,
EN 60745-2-2.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY

Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 23.07.2015

Assembly

Battery Charging



Use only the battery chargers listed on the accessories
page.

Only these battery chargers are matched to the lith-

ium-ion battery of your power tool.

Note:

The battery supplied is partially charged. To ensure full

capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.

The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.

The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.



Do not continue to press the On/Off switch after the
machine has been automatically switched off.

The bat-

tery can be damaged.

Observe the notes for disposal.

Removing the battery

The battery

9

 is equipped with two locking levels that should

prevent the battery from falling out when pushing the battery
unlocking button

7

 unintentionally. As long as the battery is

inserted in the power tool, it is held in position by means of a
spring.

To remove the battery

9

, press the battery unlocking button

7

and pull the battery out of the power tool toward the rear.

Do

not exert any force.

Battery Charge-control Indication

The battery charge-control indicator consists of three green
LEDs, and indicates the charge condition of the battery for a
few seconds when the On/Off switch is pressed halfway or ful-
ly.

The 3 LEDs of the battery charge-control indicator flash
rapidly when the battery temperature is not within the op-
erating temperature range of –30 to +65 ° C, and/or when
the overload protection has responded.

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9

LED

Capacity

Continuous lighting 3 x green

≥ 66 %

Continuous lighting 2 x green

33 – 66 %

Continuous lighting 1 x green

11 – 33 %

Slow flashing 1 x green

≤ 10 %
