Removing the battery

To remove the battery

(7)

, press the release buttons

(6)

 and

pull the battery back and out of the power tool.

 Do not use

force to do this.

Changing the Tool (see figure A)

u

Remove the battery from the power tool before carry-
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage.

 There is risk of injury

from unintentionally pressing the on/off switch.

Pull the depth stop

(4)

 off towards you. Pull the screwdriver

bit

(1)

 out. If required, the universal bit holder

(11)

 can also

be pulled out and replaced.
An auxiliary tool can be used to remove the screwdriver bit
or universal bit holder.
After changing the tool, reattach the depth stop

(4)

.

Operation

Starting Operation

Inserting the Battery
Note:

 The use of batteries unsuitable for your power tool can

lead to malfunctions or damage to the power tool.
Set the rotational direction switch

(5)

 to the middle position

to avoid unintentionally switching it on. Insert the charged
battery

(7)

 into the handle until you feel it engage and it is

flush with the handle.

Setting the Rotational Direction

The rotational direction switch

(5)

 is used to change the ro-

tational direction of the power tool. However, this is not pos-
sible while the on/off switch

(10)

 is being pressed.

Right rotation:

 Slide the rotational direction switch

(5)

 all the way into position

 on both sides.

Left rotation:

 Slide the rotational direction switch

(5)

all the way into position

 on both sides.

Switching on/off

To

start

 the power tool, press and hold the on/off switch

(10)

.

The LED

(9)

 lights up when the on/off switch

(10)

 is lightly

or fully pressed, meaning that the work area is illuminated in
poor lighting conditions.
To

switch off

 the power tool, release the on/off switch

(10)

.

Adjusting the Speed

You can adjust the speed of the power tool when it is on by
pressing in the on/off switch

(10)

 to varying extents.

A light pressure on the on/off switch

(10)

 results in a low ro-

tational speed. Increased pressure on the switch causes an
increase in speed.

Adjusting the screw-in depth (see figure B)

The depth to which the screw head is screwed into the work-
piece can be preset by turning the adjusting sleeve

(3)

 to 8

engaging steps for each rotation. Each step corresponds to a
0.25 mm change in the screw-in depth.
Turning the adjusting sleeve

(3)

 clockwise increases the

screw-in depth; turning it anticlockwise decreases the
screw-in depth.
The best way to determine the setting you require is to drive
in some test screws.

Temperature-dependent overload protection

In normal conditions of use, the power tool cannot be over-
loaded. If the power tool is overloaded or not kept within the
permitted battery temperature range, the power output is
reduced or the power tool is switched off. The power tool
will not run at full power output again until the permitted bat-
tery temperature has been reached.

Protection against deep discharge

The lithium-ion battery is protected against deep discharge
by the Electronic Cell Protection (ECP). When the battery is
discharged, the power tool is switched off by means of a pro-
tective circuit: The application tool no longer rotates.

Practical advice

u

Only apply the power tool to the screw when the tool
is switched off.

 Rotating application tools can slip off.

Place the screw against the screwdriver bit

(1)

. The screw

will be held in place by the magnetic retention force of the
universal bit holder

(11)

. Forcefully press the tip of the

screw against the material you wish to screw until the screw
depth stop

(4)

 rests on the workpiece.

Switch the power tool on. The screw is screwed into the
workpiece until it reaches the set screw depth. The drive is
disconnected; the tool holder stops rotating. Check the
screw depth and adjust it if necessary.
To loosen screws, set the rotational direction switch

(5)

 to

anticlockwise and pull the screw depth stop

(4)

 off towards

you without turning the adjusting sleeve.
You can also work with the screw depth stop

(4)

 fitted when

adjusting the screw depth.

Maintenance and Servicing

Maintenance and Cleaning

u

Remove the battery from the power tool before carry-
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage.

 There is risk of injury

from unintentionally pressing the on/off switch.

u

To ensure safe and efficient operation, always keep
the power tool and the ventilation slots clean.

To ensure trouble-free operation of the power tool, clean the
mount of the universal bit holder

(11)

 and the screwing-

depth stop

(4)

 with compressed air at regular intervals.

After-sales service and advice on using products

Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
