Operation

Starting Operation



Observe correct mains voltage! The voltage of the pow-
er source must agree with the voltage specified on the
nameplate of the machine. Power tools marked with
230 V can also be operated with 220 V.

To save energy, only switch the power tool on when using it.

Reversing the rotational direction

The rotational direction switch

8

 is used to reverse the rota-

tional direction of the machine. However, this is not possible
with the On/Off switch

7

 actuated.

Right rotation:

 For driving in screws, push the rotational di-

rection switch

8

 left to the stop.

Left rotation:

 Push the rotational direction switch

8

 right to

the stop (for unscrewing screws).

Switching On and Off

To

start

 the machine, press the On/Off switch

7

 and keep it

pressed.

To

 lock

the pressed On/Off switch

7

, press the lock-on button

6

.

To

switch off

 the machine, release the On/Off switch

7

 or

when it is locked with the lock-on button

6

, briefly press the

On/Off switch

7

 and then release it.

Adjusting the Speed

The speed of the switched-on power tool can be variably ad-
justed, depending on how far the On/Off switch

7

 is pressed.

Light pressure on the On/Off switch

7

 results in a low rotation-

al speed. Further pressure on the switch results in an increase
in speed.

Adjusting the Screw-in Depth (see figure B)

With the adjustment sleeve

3

, the screw-in depth of the screw

head into the workpiece can be preset in 8 locking steps per
full turn. Each step corresponds with a 0.25 mm change of
the screw-in depth.

Turning the adjustment sleeve

3

 in clockwise direction results

in a greater screw-in depth; turning in anticlockwise direction
reduces the screw-in depth.

The required setting is best determined by testing.

Working Advice



Before any work on the machine itself, pull the mains
plug.



Apply the power tool to the screw only when it is
switched off.

Rotating tool inserts can slip off.

Guide the screw toward the screwdriving bit

1

. The screw is

held in place by the magnet pull of the universal bit holder

10

.

Firmly push the tip of the screw into the material to be
screwed until the screwing-depth stop

4

 faces against the

workpiece.

Switch the machine on. The screw is screwed into the materi-
al until the adjusted screw-in depth is reached. The drive is
disengaged and the tool holder no longer rotates. Check the
screw-in depth and readjust, if required.

For unscrewing screws, set the rotational direction switch

8

to left rotation and pull off the screwing-depth stop

4

 toward

the front without turning the adjustment sleeve.
Working with the screwing-depth stop

4

 is also possible when

adapting the screw-in depth.

Belt Clip

With the belt clip

5

, the machine can be hung onto a belt. The

user has both hands free and the machine is always at hand.

Maintenance and Service

Maintenance and Cleaning



Before any work on the machine itself, pull the mains
plug.



For safe and proper working, always keep the machine
and ventilation slots clean.

If the replacement of the supply cord is necessary, this has to
be done by Bosch or an authorized Bosch service agent in or-
der to avoid a safety hazard.

In all correspondence and spare parts order, please always in-
clude the 10-digit article number given on the type plate of
the machine.

After-sales Service and Application Service

Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:

www.bosch-pt.com

Bosch’s application service team will gladly answer questions
concerning our products and their accessories.

Great Britain

Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or arrange
the collection of a product in need of servicing or repair.
Tel. Service: (0344) 7360109
E-Mail: boschservicecentre@bosch.com

Ireland

Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: (01) 4666700
Fax: (01) 4666888
