English |

19

Observe the relevant regulations in your country for the ma-
terials to be worked.

u

Avoid dust accumulation at the workplace.

Dust can

easily ignite.

Operation

Starting Operation

Inserting the battery
Note:

 The use of batteries unsuitable for your power tool can

lead to malfunctions or damage to the power tool.
Set the rotational direction switch

(16)

 to the middle posi-

tion to avoid unintentionally switching it on. Insert the
charged battery

(11)

 into the handle until you feel it engage

and it is flush with the handle.

Setting the rotational direction (see figure B)

The rotational direction switch

(16)

 is used to change the ro-

tational direction of the power tool. However, this is not pos-
sible while the on/off switch

(17)

 is being pressed.

Rotate clockwise:

 Slide the rotational direction

switch

(16)

 on both sides until it stops in the

 posi-

tion.

Rotate anti-clockwise:

 Slide the rotational direction

switch

(16)

 on both sides until it stops in the

 posi-

tion.

Setting the operating mode

Drilling

Set the mode selector switch

(8)

 to the

"drilling" symbol.

Screwdriving

Set the mode selector switch

(8)

 to the "screw-

driving" symbol.

Impact drilling (GSB 18V-110 C)

Set the mode selector switch

(8)

 to the "impact

drilling" symbol.

Switching on/off

To

start

 the power tool, press and hold the on/off switch

(17)

.

The LED

(13)

 lights up when the on/off switch

(17)

 is lightly

or fully pressed, meaning that the work area is illuminated in
poor lighting conditions.
To

switch off

 the power tool, release the on/off switch

(17)

.

Adjusting the Speed

You can adjust the speed of the power tool when it is on by
pressing in the on/off switch

(17)

 to varying extents.

A light pressure on the on/off switch

(17)

 results in a low ro-

tational speed. Increased pressure on the switch causes an
increase in speed.

Preselecting torque (applies to screwdriving mode)

The torque presetting ring

(7)

 can be used to preselect the

required torque in 25 stages. Once the set torque has been
reached, the application tool will be stopped.

Mechanical gear selection

u

Only operate the gear selector (9) when the power
tool is not in use.

First gear:

Low speed range; for working with a large drilling diameter
or for screwdriving.

Second gear:

High speed range; for working with a small drilling diameter.

u

Always push the gear selector switch as far as it will
go.

 Otherwise, the power tool may become damaged.

Temperature-dependent overload protection

When used as intended, the power tool cannot be over-
loaded. In the event of overloading or the temperature
rising/falling outside the permitted operating temperature
range, the speed will be reduced. The power tool will not run
at full speed again until the permitted operating temperature
has been reached.
Activation of the temperature-controlled overload protector
is indicated by the LED

(14)

 on the power tool lighting up

red. To return to within the permitted operating temperature
range, switch the gear selector

(9)

 to first gear, run the

power tool at no load or wait until the LED

(14)

 goes out.

When the LED

(14)

 has gone out, the tool has returned to

within the permitted operating temperature range.

Emergency switch-off (KickBack Control)

u

The emergency switch-off function (KickBack Con-
trol) gives the user greater control over the power
tool and offers them better protection than power
tools that do not have KickBack Control. The power
tool will switch off if it suddenly and unforeseeably ro-
tates around the drilling axis.

Emergency switch-off is indicated by the LED on the power
tool flashing.
To

switch the tool back on

, release the on/off switch and

then press it again.

u

If the KickBack Control function is defective, it will no
longer be possible to switch the power tool on. Have
the power tool serviced by a qualified repair person
using only original replacement parts.

Connectivity functions

In conjunction with the GCY 30-4

Bluetooth

® Low Energy

Module (accessory), the following connectivity functions are
available for the power tool:
– Registration and personalisation
– Status check, output of warning messages
– General information and settings
– Management
Read the corresponding operating instructions for informa-
tion about the GCY 30-4

Bluetooth

® Low Energy Module.
