10

 | English

1 609 92A 34M | (15.9.16)

Bosch Power Tools

Operation

Starting Operation

Inserting the battery
Note:

Use of batteries not suitable for the machine can lead to

malfunctions of or cause damage to the power tool.

Set the rotational direction switch

10

 to the centre position in

order to avoid unintentional starting. Insert the charged bat-
tery

7

 into the handle so that it can be felt to engage and faces

flush against the handle.

Reversing the rotational direction (see figure B)

The rotational direction switch

10

 is used to reverse the rota-

tional direction of the machine. However, this is not possible
with the On/Off switch

11

 actuated.

Right Rotation:

 For drilling and driving in screws, push the

rotational direction switch

10

 left to the stop.

Left Rotation:

 For loosening or unscrewing screws, push the

rotational direction switch

10

 right to the stop.

Setting the operating mode

Drilling
GSR 140-LI, GSR 180-LI:

Set the torque selector setting ring

3

 to the re-

quired torque.

GSB 140-LI, GSB 180-LI:

Set the operating mode selector switch

4

 to the

“drilling” symbol.

Screwdriving
GSR 140-LI, GSR 180-LI:

Set the torque selector setting ring

3

 to the

“screwdriving” symbol.

GSB 140-LI, GSB 180-LI:

Set the operating mode selector switch

4

 to the

“screwdriving” symbol.

Impact drilling(GSB 140-LI, GSB 180-LI)

Set the operating mode selector switch

4

 to the

“impact drilling” symbol.

Switching On and Off

To

start

 the machine, press the On/Off switch

11

 and keep it

pressed.

The LED

9

 lights up when the On/Off switch

11

 is halfway or

fully pressed, and enables illumination of the screwing loca-
tion in unfavourable light conditions.

To save energy, only switch the power tool on when using it.

Adjusting the Speed

The speed of the switched-on power tool can be variably ad-
justed, depending on how far the On/Off switch

11

 is

pressed.

Light pressure on the On/Off switch

11

 results in a low rota-

tional speed. Further pressure on the switch results in an in-
crease in speed.

Setting the torque

With the torque preselection ring

3

, the required torque can

be preselected in 20 steps. The inserted tool is stopped as
soon as the set torque is reached.

Gear selection, mechanical



The gear selector 5 can be actuated at standstill or
when the machine is running. However, this should not
be done while operating at full load or maximum speed.

1st gear:

Low speed range; for working with large drilling diameters.

2nd gear:

High speed range; for drilling with small drilling diameter.

Temperature Dependent Overload Protection

In normal conditions of use, the power tool cannot be over-
loaded. If the power tool is overloaded or the battery temper-
ature is not kept within the permitted range, the power tool
switches off and the LED on the power tool flashes. Allow the
power tool to cool down before you carry on working.

Protection Against Deep Discharging

The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.

Rapid Shut-off

The rapid shut-off feature enables better control of the power
tool. The power tool shuts off in case of sudden and unexpect-
ed rotation of the power tool around the drilling axis.

The rapid shut-off feature is indicated by a flashing LED on the
power tool.

To

restart the machine

, release the On/Off switch and then

actuate again.



Rapid shut-off can trigger only when the power tool is
running at maximum operating speed and can rotate
freely around the drill bit axis.

Choose a suitable work

position for this. Otherwise, rapid shut-off will not be en-
sured.

Working Advice



Always push the gear selector and turn the operating
mode selector switch through to the stop.

Otherwise,

the machine can become damaged.



Apply the power tool to the screw only when it is
switched off.

Rotating tool inserts can slip off.

An auxiliary tool can be used to remove the screwdriver bit or
universal bit holder.



Working in especially dusty environments can lead to
failure of the power tool. If the power tool suddenly
fails, remove the carbon brushes and check them (see
section “Replacing the Carbon Brushes”).
