Technical Data

The technical data of the machine are listed in the table on
page 151.

Please observe the article number on the type plate of your
machine. The trade names of the individual machines may
vary.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardisation documents: EN 60745
according to the provisions of the directives 2009/125/EC
(Regulation 1194/2012), 2011/65/EU, 2004/108/EC,
2006/42/EC.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen

Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
18.04.2013

Noise/Vibration Information

The measured values of the machine are listed in the table on
page 151.

Noise and vibrational values (vector sum of three directions)
determined according to EN 60745.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Mounting and Operation

Maintenance and Cleaning



For safe and proper working, always keep the machine
and ventilation slots clean.

Clean the application tool, the tool holder, the power tool’s
ventilations slots, and the battery’s ventilation slots each time
after using.

After-sales Service and Application
Service

Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:

www.bosch-pt.com

Bosch’s application service team will gladly answer questions
concerning our products and their accessories.

In all correspondence and spare parts order, please always in-
clude the 10-digit article number given on the type plate of
the machine.

Great Britain

Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: (0844) 7360109
Fax: (0844) 7360146
E-Mail: boschservicecentre@bosch.com

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9

Action

Figure

Page

Removing the battery

1

152

Inserting the battery

2

152

Checking the battery charge
condition

3

152

Changing the position of the
auxiliary handle

4

153

Mounting application tools

5

153

Reversing the rotational direction

6

154

Setting the torque

7

154

Selecting the drilling position

8

155

Setting the operating mode

9

155

Gear selection, mechanical

10

155

Switching On and Off

11

156

Selecting Accessories

–

157
