English |
17
the workpiece or when the power tool becomes over-
loaded.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended use
The power tool is intended for driving and loosening screws
and for drilling in wood, metal, ceramic and plastic. The GSB
is also designed for impact drilling in brick, masonry and
stone.
Product Features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
Tool holder
(2)
Keyless chuck
(3)
Locking sleeve (
GSR 12V-35 HX
)
(4)
Torque presetting ring
(5)
Operating mode presetting ring (GSB)
(6)
Gear selector switch
(7)
Rotational direction switch
(8)
Battery release button
A)
(9)
Rechargeable battery
A)
(10)
On/off switch
(11)
Battery charge indicator
(12)
"PowerLight" lamp
(13)
Handle (insulated gripping surface)
(14)
Screwdriver bit
A)
(15)
Universal bit holder
A)
(16)
Belt clip
A)
(17)
Bit holder
A)
(18)
Colour clip
A)
A)
Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Technical Data
Cordless drill/driver
GSB 12V-35
GSR 12V-35
GSR 12V-35 HX
Article number
3 601 JJ9 0..
3 601 JH8 0..
3 601 JJ9 1..
Rated voltage
V=
12
12
12
No-load speed
A)
– First gear
min
-1
0–460
0–460
0–460
– Second gear
min
-1
0–1 750
0–1 750
0–1 750
Impact rate
A)
min
-1
26 250
–
–
Max. torque, hard/soft screw-
driving application according
to ISO 5393
A)
Nm
35/20
35/20
35/20
Max. drilling diameter (first/second gear)
– Masonry
mm
10
–
–
– Steel
mm
10
10
10
– Wood
mm
32
32
32
Chuck capacity
mm
0.8–10
0.8–10
–
Tool holder
mm
–
–
6.35 ¼"
Max. screw diameter
mm
8
8
8
Weight according to
EPTA-Procedure 01:2014
A)
kg
1.0–1.2
0.93–1.2
0.75–1.0
Recommended ambient tem-
perature during charging
°C
0 to +35
0 to +35
0 to +35
Permitted ambient temperat-
ure during operation
B)
and dur-
ing storage
°C
–20 to +50
–20 to +50
–20 to +50
Recommended rechargeable
batteries
GBA 12V...
GBA 12V...
GBA 12V...
Bosch Power Tools
1 609 92A 5ES | (09.03.2020)
