12

 | English

1 609 92A 3L7 | (5.10.16)

Bosch Power Tools



Use the battery only in conjunction with your Bosch
power tool.

This measure alone protects the battery

against dangerous overload.



The battery can be damaged by pointed objects such as
nails or screwdrivers or by force applied externally.

An

internal short circuit can occur and the battery can burn,
smoke, explode or overheat.

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for driving in and loosening screws
as well as for drilling in wood, metal, ceramic and plastic.

The light of this power tool is intended to illuminate the power
tool’s direct area of working operation and is not suitable for
household room illumination.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Tool holder

2

Torque presetting ring

3

Gear selector

4

Battery unlocking button *

5

Battery pack *

6

Rotational direction switch

7

On/Off switch

8

“PowerLight”

9

Handle (insulated gripping surface)

10

Screwdriver bit *

11

Universal bit holder *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-1.

Typically the A-weighted sound pressure level of the product
is 66 dB(A). Uncertainty K = 3 dB.
The noise level when working can exceed 80 dB(A).

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745-2-1:
Screwdriving without impact: a

h

< 2.5 m/s

2

, K = 1.5 m/s

2

Drilling into metal: a

h

< 2.5 m/s

2

, K = 1.5 m/s

2

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2009/125/EC (Regulation
1194/2012), 2011/65/EU, until 19 April 2016:
2004/108/EC, from 20 April 2016 on: 2014/30/EU,

Cordless Drill/Driver

GSR 120-LI

Article number

3 601 JF7 0..

Rated voltage

V=

12

No-load speed

–

1st gear

–

2nd gear

min

-1

min

-1

0 – 380

0 – 1300

* depending on the battery pack being used

** Limited performance at temperatures < 0 ° C

Max. torque for hard/soft
screwdriving application
according to ISO 5393

Nm

30/ 13*

Max. drilling dia.

–

Steel

–

Wood

mm
mm

8

20

Max. screw dia.

mm

7

Weight according to
EPTA-Procedure 01:2014

kg

0.99/1.17*

Permitted ambient temperature

–

during charging

–

during operation

**

 and during

storage

° C

° C

0...+45

-15...+50

Recommended batteries

GBA 12 V...

Recommended chargers

GAL 12.. CV

Cordless Drill/Driver

GSR 120-LI

* depending on the battery pack being used

** Limited performance at temperatures < 0 ° C
