 English |

13

Bosch Power Tools

1 609 92A 2P0 | (27.7.16)

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, un-

fold the graphics page for the machine and leave it open.

Intended Use

The machine is intended for driving in and loosening screws
as well as for drilling in wood, metal, ceramic and plastic.

The light of this power tool is intended to illuminate the power
tool’s direct area of working operation and is not suitable for
household room illumination.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Keyless chuck

2

Torque presetting ring

3

Gear selector

4

Battery unlocking button *

5

Battery pack *

6

Rotational direction switch

7

On/Off switch

8

Battery charge-control indicator

9

“PowerLight”

10

Handle (insulated gripping surface)

11

Universal bit holder *

12

Screwdriver bit *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-1.

Typically the A-weighted sound pressure level of the product
is 71 dB(A). Uncertainty K = 3 dB.
The noise level when working can exceed 80 dB(A).

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745-2-1.

Drilling into metal: a

h

< 2.5 m/s

2

, K = 1.5 m/s

2

Screwdriving without impact: a

h

< 2.5 m/s

2

, K = 1.5 m/s

2

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Assembly

Battery Charging (see figure A)



Use only the battery chargers listed on the accessories
page.

Only these battery chargers are matched to the lith-

ium-ion battery of your power tool.

Note:

The battery supplied is partially charged. To ensure full

capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.

The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.

Cordless Drill/Driver

GSR 12V-15

Article number

3 601 H68 1..

Rated voltage

V=

12

No-load speed
– 1st  gear
– 2nd  gear

min

-1

min

-1

0 – 400

0 – 1300

Max. torque for hard/soft screwdriv-
ing application according to
ISO 5393

Nm

30 / 15*

Max. drilling dia.
– Steel
– Wood

mm
mm

10
19

Max. screw dia.

mm

7

Chuck clamping range

mm

1.0 – 10

Weight according to
EPTA-Procedure 01:2014

kg

1.0 – 1.2*

*  depending on the battery pack being used

** limited performance at temperatures < 0 ° C

Permitted ambient temperature
– during charging
– during operation** and during

storage

°C

°C

0...+45

-20...+50

Recommended batteries

GBA 12V..

GBA 10,8V..

Recommended chargers

GAL 12.. CV

AL 11..CV

Cordless Drill/Driver

GSR 12V-15

*  depending on the battery pack being used

** limited performance at temperatures < 0 ° C
