English |

13

Technical Data

Impact drill

GSB 16 RE

GSB 16 RE

Article number

3 601 A4E 5..

3 601 A4E 6..

Rated power input

W

750

750

Power output

W

380

380

No-load speed

min

-1

0–2 800

0–2 800

Rated speed

min

-1

1 750

1 750

Impact rate at no-load speed

min

-1

47 600

47 600

Rated torque

Nm

2.3

2.3

Max. drilling diameter

– Concrete

mm

16

16

– Masonry

mm

18

18

– Steel

mm

13

13

– Wood

mm

30

30

Speed preselection

●

●

Clockwise/anti-clockwise rotation

●

●

Keyed chuck

–

●

Keyless chuck

●

–

Chuck capacity

mm

1.5–13

1.5–13

Fully automatic spindle lock (Auto-Lock)

●

–

Spindle collar diameter

mm

43

43

Weight according to
EPTA-Procedure 01:2014

kg

2.2

2.2

Protection class

 / II

 / II

The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models.

Noise/vibration information

Noise emission values determined according to

EN 62841-2-1

.

Typically the A-weighted noise level of the power tool are:

96

dB(A); sound power level

107

 dB(A). Uncertainty K =

5

 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to

EN 62841-2-1

:

Drilling into metal: a

h

 =

5.5

 m/s

2

, K =

1.5

 m/s

2

Impact drilling into concrete: a

h

 =

15

 m/s

2

, K =

2.4

 m/s

2

Screwdriving: a

h

 <

2.5

 m/s

2

, K =

1.5

 m/s

2

Thread cutting: a

h

 <

2.5

 m/s

2

, K =

1.5

 m/s

2

The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure and may be used to com-
pare power tools. They may also be used for a preliminary
estimation of vibration and noise emissions.
The stated vibration level and noise emission value repres-
ent the main applications of the power tool. However, if the
power tool is used for other applications, with different ap-
plication tools or is poorly maintained, the vibration level
and noise emission value may differ. This may significantly
increase the vibration and noise emissions over the total
working period.

To estimate vibration and noise emissions accurately, the
times when the tool is switched off or when it is running but
not actually being used should also be taken into account.
This may significantly reduce vibration and noise emissions
over the total working period.
Implement additional safety measures to protect the oper-
ator from the effects of vibration, such as servicing the
power tool and application tools, keeping their hands warm,
and organising workflows correctly.

Assembly

u

Pull the plug out of the socket before carrying out any
work on the power tool.

Auxiliary handle (see figure A)

u

Do not operate your power tool without the auxiliary
handle

(7)

.

You can swivel the auxiliary handle

(7)

 to any angle for a safe

work posture that minimises fatigue.
Turn the lower gripping end of the auxiliary handle

(7)

 anti-

clockwise and swivel the auxiliary handle

(7)

 into the re-

quired position. Afterwards, turn the lower gripping end of
the auxiliary handle

(7)

 clockwise to retighten it.
