Delivery Scope
Combination cordless drill.
Battery, application tools and other accessories shown or de-
scribed are not part of the standard delivery scope.
A complete overview of accessories can be found in our ac-
cessories program.
Intended Use
The machine is intended for driving in and loosening screws
as well as for drilling in wood, metal, ceramic and plastic and
for impact drilling in brick, brickwork and masonry.
Technical Data
The technical data of the machine are listed in the table on
page 152.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2011/65/EU, until
19 April 2016: 2004/108/EC, from 20 April 2016 on:
2014/30/EU, 2006/42/EC including their amendments and
complies with the following standards:
EN 60745-1, EN 60745-2-1, EN 60745-2-2, EN 50581.
Technical file (2006/42/EC) at:
Robert Bosch Power Tools GmbH, PT/ECS,
70538 Stuttgart, GERMANY
Read all safety warnings and all
instructions
Before any work on the machine itself,
remove the battery
Always wear ear protection
Movement direction
Reaction direction
Right/left rotation
Screwdriving
Drilling without impact
Impact drilling
Low speed
High speed
Switching On
Switching Off
U
Rated voltage
n
0
1
No-load speed (1. gear)
n
0
2
No-load speed (2. gear)
n
S
Impact rate
M
Maximum torque according to ISO 5393
Brickwork
Metal
Wood
Ø
Drilling diameter, max.
Ø
Max. screw dia.
Chuck clamping range
Weight according to EPTA-Procedure
01:2014
*
Value dependent of the battery pack
being used
L
wA
Sound power level
Symbol
Meaning
L
pA
Sound pressure level
K
Uncertainty
a
h
Vibration total value
T
1
Permitted ambient temperature during
charging
T
2
Permitted ambient temperature during
operation
*
and storage
* Limited performance at temperatures
< 0 ° C
Recommended batteries
Recommended chargers
Henk Becker
Executive Vice President
Engineering
Helmut Heinzelmann
Head of Product Certification
PT/ECS
Symbol
Meaning
