English |
13
Bosch Power Tools
2 609 140 727 | (11.4.12)
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions.
Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
While reading the operating instructions, unfold the graphics
page for the machine and leave it open.
Intended Use
The machine is intended for driving in and loosening screws
as well as for drilling in wood, metal, ceramic and plastic and
for impact drilling in brick, brickwork and stone.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1
Keyless chuck
2
Torque preselection ring
3
Operating mode preselection ring
4
Gear selector
5
Screwdriver bit *
6
Battery pack *
7
Battery unlocking button *
8
Rotational direction switch
9
On/Off switch
10
Handle (insulated gripping surface)
11
Universal bit holder *
* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:
Sound pressure level 87 dB(A); Sound power level 98 dB(A).
Uncertainty K = 3 dB.
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745:
Drilling into metal: a
h
< 2.5 m/s
2
, K = 1.5 m/s
2
,
Impact drilling into concrete: a
h
= 17 m/s
2
, K = 4.0 m/s
2
,
Screwdriving without impact: a
h
< 2.5 m/s
2
, K = 1.5 m/s
2
.
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep hands warm, organise work patterns.
Technical Data
Combination Cordless Drill
GSB 12-2
GSB 14,4-2
Article number
3 601 JA7 5..
3 601 JA7 4..
Rated voltage
V=
12
14.4
No-load speed
– 1st gear
– 2nd gear
min
-1
min
-1
0 – 450
0 – 1 250
0 – 550
0 – 1 550
Impact frequency at no-load
min
-1
0 – 18 750
0 – 23 250
Max. torque for hard/soft screwdriving application according to ISO 5393
Nm
30 / 18
36 / 20
Max. screw dia.
mm
7
8
Max. drilling dia.
– Steel
– Wood
– Brickwork
mm
mm
mm
10
25
8
10
25
10
Chuck clamping range
mm
1.5 – 10
1.5 – 10
Drill spindle thread
½"
½"
Weight according to EPTA-Procedure 01/2003
kg
1.6
1.7
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
OBJ_BUCH-1124-003.book Page 13 Wednesday, April 11, 2012 11:41 AM
