English |

13

u

Apply pressure only in direct line with the bit and do
not apply excessive pressure.

Bits can bend causing

breakage or loss of control, resulting in personal injury.

Additional safety warnings

u

Switch the power tool off immediately if the applica-
tion tool becomes blocked. Be prepared for high
torque reactions which cause kickback.

 The applica-

tion tool becomes blocked when it becomes jammed in
the workpiece or when the power tool becomes over-
loaded.

u

Hold the power tool securely.

When tightening and

loosening screws be prepared for temporarily high torque
reactions.

u

Secure the workpiece.

 A workpiece clamped with

clamping devices or in a vice is held more secure than by
hand.

u

Use suitable detectors to determine if there are hid-
den supply lines or contact the local utility company
for assistance.

 Contact with electric cables can cause

fire and electric shock. Damaging gas lines can lead to ex-
plosion. Breaking water pipes causes property damage.

u

Always wait until the power tool has come to a com-
plete stop before placing it down.

 The application tool

can jam and cause you to lose control of the power tool.

u

In case of damage and improper use of the battery, va-
pours may be emitted. The battery can set alight or ex-
plode.

Ensure the area is well ventilated and seek medical

attention should you experience any adverse effects. The
vapours may irritate the respiratory system.

u

Do not open the battery.

There is a risk of short-circuit-

ing.

u

The battery can be damaged by pointed objects such
as nails or screwdrivers or by force applied externally.

An internal short circuit may occur, causing the battery to
burn, smoke, explode or overheat.

u

Only use the battery with products from the manufac-
turer.

 This is the only way in which you can protect the

battery against dangerous overload.

Protect the battery against heat, e.g.
against continuous intense sunlight, fire,
water and moisture.

 There is a risk of explo-

sion.

Product Description and
Specifications

Read all the safety and general instructions.

Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.

Please observe the illustrations at the beginning of this oper-
ating manual.

Intended use

The power tool is intended for tightening and loosening
screws, as well as for drilling in wood, metal and plastic and
for impact drilling in brick, concrete and stone.

Product Features

The numbering of the product features refers to the diagram
of the power tool on the graphics page.

(1)

Keyless chuck

(2)

Operating mode setting ring

(3)

Operating mode indicator

(4)

Rotational direction indicator for clockwise rotation
(drilling and driving in screws)

(5)

Rotational direction indicator for anti-clockwise rota-
tion (unscrewing screws)

(6)

Battery charge indicator

(7)

Electronic rotational direction switch

(8)

Handle (insulated gripping surface)

(9)

Battery release button

(10)

Battery

A)

(11)

On/off switch

(12)

Worklight

(13)

Universal bit holder

A)

(14)

Screwdriver bit

A)

(15)

Drill bit

A)

A)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical Data

Impact drill

EasyImpact 12

Article number

3 603 JB6 1..

Rated voltage

V

12

No-load speed

– First gear

min

-1

0–400

– Second gear

min

-1

0–1300

Impact rate at no-load speed

bpm

19,500

Max. torque, hard/soft
screwdriving application ac-
cording to ISO 5393

Nm

15/30

Torque settings

12 (11 + Max)

Tightening torque range

Nm Min. 0.7–max. 2.8

Max. drilling diameter (first/second gear)

– Steel

mm

8

– Wood

mm

20

– Brick/limestone

mm

6

Max. screw diameter

mm

6

Max. drill chuck clamping
width

mm

10
