English |
17
u
The battery can be damaged by pointed objects such
as nails or screwdrivers or by force applied externally.
An internal short circuit may occur, causing the battery to
burn, smoke, explode or overheat.
u
Only use the battery with products from the manufac-
turer.
This is the only way in which you can protect the
battery against dangerous overload.
Protect the battery against heat, e.g. against
continuous intense sunlight, fire, dirt, water
and moisture.
There is a risk of explosion and
short-circuiting.
u
Do not hold the power tool by the unlocking ring dur-
ing operation or transportation.
Pulling on the unlock-
ing ring unintentionally can release the adapter and lead
to injuries or damage to the tool.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended use
The power tool is intended for driving and loosening screws
and for drilling in wood, metal, ceramic and plastic. The
cordless drill/driver
AdvancedImpact 18
is also designed
for impact drilling in brick, masonry and stone.
Product Features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
Unlocking ring
(2)
Tool holder
(3)
Torque presetting ring
(4)
Mode selector switch
(5)
Right rotational direction indicator
(6)
Left rotational direction indicator
(7)
Electronic rotational direction switch
(8)
Battery release button
A)
(9)
Battery
A)
(10)
Handle (insulated gripping surface)
(11)
Magnetic bit holder
(12)
Light
(13)
Battery charge indicator
(14)
On/off switch
(15)
Magnetic cap
(16)
Screw holder
(17)
Angle screw adapter
A)
(18)
Drill chuck adapter
A)
(19)
Off-set angle adapter
A)
(20)
Screwdriver bit
A)
(21)
Universal bit holder
A)
A)
Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Technical Data
Cordless drill/driver
AdvancedDrill 18
AdvancedImpact 18
Article number
3 603 JB5 0..
3 603 JB5 1..
Rated voltage
V=
18
18
No-load speed
A)
– Screws (first screw phase)
min
-1
0–430
0–450
– Drilling/impact drilling (second screw
phase)
min
-1
0–1350
0–1500
Impact rate
A)
min
-1
–
0–22,500
Max. torque, hard/soft screwdriving applica-
tion according to ISO 5393
A)
Nm
36/24
36/22
Max. torque
A)
Nm
42
39
Max. drilling diameter
– Masonry
mm
–
11
– Steel
mm
13
13
– Wood
mm
35
35
Tool holder
1.5–13
1.5–13
Max. screw diameter
mm
10
10
Weight according to EPTA-Procedure
01:2014
B)
kg
1.3 (1.5 Ah)–1.6 (6.0 Ah)
1.4 (1.5 Ah)–1.7 (6.0 Ah)
Bosch Power Tools
1 609 92A 5W6 | (31.07.2020)
