ENGLISH
If the supply cord is damaged, it must be re-
placed by the manufacturer or an authorised
Black & Decker Service Centre in order to avoid
a hazard.
Features
1.
Variable speed switch
2. Lock-on
button
3. Forward/reverse
button
4. Drilling mode selector
5. Chuck
6. Depth stop (not all models)
7. Side handle (not all models)
fi
g. B
8. Manual spindle lock button (single sleeve key-
less chuck only)
Assembly
Warning!
Before assembly, make sure that the tool
is switched off and unplugged.
Fitting the side handle and depth stop (
fi
g. A)
Turn the grip counter clockwise until you can
slide the side handle (7) onto the front of the
tool as shown.
Rotate the side handle into the desired posi-
tion.
Insert the depth stop (6) into the mounting hole
as shown.
Set the drilling depth as described below.
Tighten the side handle by turning the grip
clockwise.
Fitting a drill bit
Single sleeve keyless chuck (
fi
g. B)
Open the chuck by pressing the manual spindle
lock button (8) and turning the sleeve (9) counter
clockwise.
Insert the bit shaft (12) into the chuck.
Firmly tighten the chuck by pressing the manual
spindle lock button (8) and turning the sleeve
clockwise until it is tight.
Two sleeve keyless chuck (
fi
g. C)
Open the chuck by turning the sleeve (13) coun-
ter clockwise.
Insert the bit shaft (12) into the chuck and
fi
rmly
tighten the chuck.
Keyed chuck (
fi
g. D)
Open the chuck by turning the sleeve (11) coun-
ter clockwise.
Insert the bit shaft (12) into the chuck.
Insert the chuck key (14) into each hole (15) in
the side of the chuck and turn clockwise until
tight.
Removing and re
fi
tting the chuck (
fi
g. E)
Open the chuck as far as possible.
Remove the chuck retaining screw, located
in the chuck, by turning it clock wise using
a screwdriver.
Tighten an Allen key into the chuck and strike it
with a hammer as shown.
Remove the Allen key.
Remove the chuck by turning it counter clock-
wise.
To re
fi
t the chuck, screw it onto the spindle and
secure it with the chuck retaining screw.
Residual risks
Additional residual risks may arise when using the
tool which may not be included in the enclosed
safety warnings. These risks can arise from misuse,
prolonged use etc.
Even with the application of the relevant safety
regulations and the implementation of safety de-
vices, cer tain residual risks cannot be avoided.
These include:
Injuries caused by touching any rotating/moving
parts.
Injur ies c aused when c hanging any par ts,
blades or accessories.
Injuries caused by prolonged use of a tool. When
using any tool for prolonged periods make sure
you take regular breaks.
Impairment of hearing.
Health hazards caused by breathing dust devel-
oper when using your tool (example:- working
with wood, especially oak, beech and MDF).
Use
Warning!
Let the tool work at its own pace. Do not
overload.
Warning!
Before drilling into walls,
fl
oors or ceilings,
check for the location of wiring and pipes.
Selecting the direction of rotation (
fi
g. F)
For drilling and for tightening screws, use forward
(clockwise) rotation. For loosening screws or re-
moving a jammed drill bit, use reverse (counter
clockwise) rotation.
To select forward rotation, push the forward/re-
verse button (3) to the left position.
To select reverse rotation, push the forward/re-
verse button to the right.
Warning!
Never change the direction of rotation
while the motor is running.
