  SB2E 750 RX ST

SB2E 720 RX ST

SB2-750 ST

  SB2E 750 R ST

............. 750 W................................ 720 W ......................... 750  W

............. 375 W................................ 360 W ......................... 375  W

........ 0-1200 min

-1

 .................. 0-1200 min

-1

 ............... 1200 min

-1

........ 0-3400 min

-1

 .................. 0-3400 min

-1

 ............... 3400 min

-1

............. 750 min

-1

 ....................... 770 min

-1

 ................. 750 min

-1

........... 2100 min

-1

 ..................... 2200 min

-1

 ............... 2100 min

-1

....... 31500 min

-1

 ................... 33000 min

-1

 ............. 31500 min

-1

........ 62/30 Nm ...................... 60/29 Nm ................ 62/30 Nm

.......... 20/10 mm .......................... 20/10 mm .................... 20/10  mm

.......... 22/12 mm .......................... 22/12 mm .................... 22/12  mm

............ 13/8 mm ............................ 13/8 mm ...................... 13/8  mm

............... 40 mm ............................... 40 mm ......................... 40  mm

............... 16 mm ............................... 16 mm ......................... 16  mm

............... 30 mm ............................... 30 mm ......................... 30  mm

............... 12 mm ............................... 12 mm ......................... 12  mm

........... 6x90 mm ............................6x90 mm ......................6x90  mm

........... 5x60 mm ............................5x60 mm ......................5x60  mm

......... 1,5-13 mm ......................... 1,5-13 mm ................... 1,5-13  mm

....... 1/2"x20  ............................. 1/2"x20  ....................... 1/2"x20

............... 43 mm ............................... 43 mm ......................... 43  mm

.............. 2,5 kg ................................ 2,5 kg .......................... 2,5  kg

............. 101 dB (A) ......................... 101 dB (A) ....................101  dB (A)

..............112 dB (A) ..........................112 dB (A) ....................112  dB (A)

.............. 3,5 m/s

2

 ............................. 3,5 m/s

2

 ....................... 3,5  m/s

2

.............. 1,5 m/s

2

 ............................. 1,5 m/s

2

 ....................... 1,5  m/s

2

............ 12,5 m/s

2

 ........................... 12,5 m/s

2

 ..................... 12,5  m/s

2

.............. 1,5 m/s

2

 ............................. 1,5 m/s

2

 ....................... 1,5  m/s

2

ENGLISH

SPECIFIED CONDITIONS OF USE

The electronic drill/screwdriver can be universally used for

drilling, percussion drilling, screwdriving and cutting screw

threads.

Do not use this product in any other way as stated for normal

use.

MAINS CONNECTION

Connect only to single-phase a.c. current and only to the

system voltage indicated on the rating plate. It is also possible

to connect to sockets without an earthing contact as the

design conforms to safety class

II

.

EC-DECLARATION OF CONFORMITY

We declare under our sole responsibility that this product is in

conformity with the following standards or standardized

documents. EN 60745, EN 55014-1, EN 55014-2, EN 61000-

3-2, EN 61000-3-3, in accordance with the regulations 98/37/

EC, 2004/108/EC

Rainer Kumpf

Manager Product Development

Winnenden, 2009-01-04

MAINTENANCE

The ventilation slots of the machine must be kept clear at all

times.

If the machine is mainly used for percussion drilling, regularly

remove collected dust from the chuck. To remove the dust

hold the machine with the chuck facing down vertically, and

completely open and close the chuck. The collected dust will

fall from the chuck. It is recommended to regularly use

cleaner  for the clamping jaws and the clamping jaw borings.
Use only AEG accessories and AEG spare parts. Should

components need to be replaced which have not been

described, please contact one of our AEG service agents (see

our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.

Please state the ten-digit No. as well as the machine type

printed on the label and order the drawing at your local

service agents or directly at: AEG Elektrowerkzeuge,

Max-Eyth-Straße 10, D-71364 Winnenden, Germany.

SYMBOLS

Please read the instructions carefully before

starting the machine.

Always disconnect the plug from the socket

before carrying out any work on the machine.

Accessory - Not included in standard

equipment, available as an accessory.

Do not dispose of electric tools together with

household waste material! In observance of

European Directive 2002/96/EC on waste

electrical and electronic equipment and its

implementation in accordance with national

law, electric tools that have reached the end

of their life must be collected separately and

returned to an environmentally compatible

recycling facility.

ENGLISH

TECHNICAL DATA

Rated input ........................................................................

Output ................................................................................

No-load speed, 1st gear ....................................................

No-load speed, 2nd gear ...................................................

Speed under load max., 1st gear ......................................

Speed under load max., 2nd gear .....................................

Rate of percussion under load max. ..................................

Static jamming moment *, 1st gear/2nd gear ....................

Drilling capacity in concrete, 1st gear/2nd gear...........................

Drilling capacity in brick and tile, 1st gear/2nd gear ....................

Drilling capacity in steel, 1st gear/2nd gear .................................

Drilling capacity in soft- wood, with Forstner bit in 1st gear.........

Drilling capacity in soft- wood, with auger bit in 1st gear .............

Drilling capacity in hard-wood with Forstner bit in 1st gear .........

Drilling capacity in hard-wood, with auger bit in 1st gear ............

Max. Spax‘s bit size in soft-wood ......................................

Max. Spax‘s bit size in hard-wood .....................................

Drill opening range ............................................................

Drive shank........................................................................

Chuck neck diameter .........................................................

Weight without cable .........................................................

Noise information

Measured values determined according to EN 60 745.

Typically, the A-weighted noise levels of the tool are:

  Sound pressure level (K = 3 dB(A)) .................................

  Sound power level (K = 3 dB(A)) .....................................

Wear ear protectors!
Vibration information

Total vibration values (vector sum in the three axes)

determined according to EN 60745.

Vibration emission value a

h

:

Drilling into metal ...............................................................

Uncertainty K .....................................................................

Percussion drilling into concrete ........................................

Uncertainty K .....................................................................

 WARNING! Read all safety warnings and all

instructions, including those given in the accompanying

brochure

. Failure to follow the warnings and instructions may

result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

SAFETY INSTRUCTIONS

Wear ear protectors.

Exposure to noise can cause hearing

loss.

Use auxiliary handles supplied with the tool.

Loss of

control can cause personal injury.Appliances used at many

different locations including open air must be connected via a

current surge preventing switch.

Hold power tool by insulated gripping surfaces, when

performing an operation where the cutting accessory

may contact hidden wiring or its own cord.

 Contact with a

„live“ wire will also make exposed metal parts of the power

tool „live“ and shock the operator.
Appliances used at many different locations including open air

should be connected via a residual current device of 30 mA or less.

Always wear goggles when using the machine. It is

recommended to wear gloves, sturdy non slipping shoes and

apron.
Sawdust and splinters must not be removed while the

machine is running.
Always disconnect the plug from the socket before carrying

out any work on the machine.
Only plug-in when machine is switched off.
Keep mains lead clear from working range of the machine.

Always lead the cable away behind you.
When working with large drill diameters, the auxiliary handle

must be fastened in a right angle with the main handle (see

illustrations, section Twisting the handle).
Do not use diamond core drills on hammer mode.

When working in walls ceiling, or floor, take care to avoid

electric cables and gas or waterpipes.

WARNING

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in

EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained, the vibration emission may differ. This may significantly increase the

exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or when it

is running but not actually doing the job. This may significantly reduce the exposure level over the total working period.

Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the

accessories, keep the hands warm, organisation of work patterns.
