16

17

S 2500 E

S 4000 E

..................... 4133 58 03...    ............. 4133 61 03...

..................... 4134 32 03...    ............. 4132 24 03...

   ...000001-999999

   ...000001-999999

......................... 720 W ........................... 720 W

......................... 360 W ........................... 360 W

....................0-2500 min

-1

 ..................0-4000 min

-1

.......................... 6,3 mm ......................... 6,3 mm

........................... 10 mm .............................-

.......................... 5,0 mm ......................... 5,0 mm

.........................1/4"  ..............................1/4"

.......................... 1,5 kg ............................ 1,4 kg

........................ 86,5 dB (A) ................... 86,5 dB (A)

........................ 97,5 dB (A) ................... 97,5 dB (A)

....................... < 2,5 m/s

2

......................< 2,5 m/s

2

.......................... 1,5 m/s

2

......................... 1,5 m/s

2

ENGLISH

ENGLISH

EN 60745-1:2009 + A11:2010

EN 60745-2-2:2010

EN 55014-1:2006 + A1:2009 + A2:2011

EN 55014-2:2015

EN 61000-3-2:2014

EN 61000-3-3:2013

EN 50581:2012

Winnenden, 2017-09-25

Alexander Krug

Managing Director
Authorized to compile the technical fi le
Techtronic Industries GmbH

Max-Eyth-Straße 10

71364 Winnenden

Germany

MAINS CONNECTION

Appliances used at many diff erent locations including wet

room and open air must be connected via a residual current

device (FI, RCD, PRCD) of 30mA or less.
Connect only to single-phase AC current and only to the

system voltage indicated on the rating plate. It is also

possible to connect to sockets without an earthing contact

as the design conforms to safety class II.
Make sure the machine is switched off  before plugging in.
This is a device for professional use which may slightly

exceed the guide values for current harmonics when it is

connected to the public low voltage mains supply. You

should therefore contact your energy supply company

before you connect the device to the public low voltage

mains supply.

MAINTENANCE

The ventilation slots of the machine must be kept clear at all

times.
Important note! If the carbon brushes are worn, in addition

to exchanging the brushes the tool should be sent to

after-sales service. This will ensure long service life and top

performance.
If the supply cord of this appliance is damaged, it must only

be replaced by a repair shop appointed by the manufacturer,

to avoid hazardous situations.
Use only AEG accessories and spare parts. Should

components need to be replaced which have not been

described, please contact one of our AEG service agents

(see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.

Please state the Article No. as well as the machine type

printed on the label and order the drawing at your local

service agents or directly at: Techtronic Industries GmbH,

Max-Eyth-Straße 10, 71364 Winnenden, Germany.

TECHNICAL DATA

Production code.......................................................................

   ..............................................................................................

Rated input ..............................................................................

Output ......................................................................................

No-load speed .........................................................................

Self-drill screws up to max.......................................................

Allen screws (key width) ..........................................................

Dry wall screws up to max. ......................................................

Universal reception ..................................................................

Weight according EPTA-Procedure 01/2003 ...........................

Noise information

Measured values determined according to EN 60745.

Typically the A-weighted sound pressure level of the tool is:

  Sound pressure level (Uncertainty K=3dB(A))......................

  Sound power level (Uncertainty K=3dB(A)) ..........................

Wear ear protectors!
Vibration information

Total vibration values (vector sum in the three axes)

determined according to EN 60745.

Vibration emission value a

h

  Screwing ...............................................................................

  Uncertainty K ........................................................................

 WARNING! Read all safety warnings and all

instructions.

 Failure to follow the warnings and instructions

may result in electric shock, fi re and/or serious injury.

Save all warnings and instructions for future reference.

 SCREWDRIVER SAFETY WARNINGS

Hold power tool by insulated gripping surfaces, when

performing an operation where the fasteners may

contact hidden wiring or its own cord.

Fasteners

contacting a "live" wire may make exposed metal parts of

the power tool "live" and could give the operator an electric

shock.

Wear ear protectors when impact drilling.

 Exposure to

noise can cause hearing loss.

ADDITIONAL SAFETY AND WORKING INSTRUCTIONS

Use protective equipment. Always wear safety glasses when

working with the machine. The use of protective clothing is

recommended, such as dust mask, protective gloves, sturdy

non-slip footwear, helmet and ear defenders.
The dust produced when using this tool may be harmful to

health. Do not inhale the dust. Wear a suitable dust

protection mask.
Do not machine any materials that present a danger to

health (e.g. asbestos).
Switch the device off  immediately if the insertion tool stalls!

Do not switch the device on again while the insertion tool is

stalled, as doing so could trigger a sudden recoil with a high

reactive force. Determine why the insertion tool stalled and

rectify this, paying heed to the safety instructions.
The possible causes may be:

•  it is tilted in the workpiece to be machined

•  it has pierced through the material to be machined

•  the power tool is overloaded
Do not reach into the machine while it is running.
The insertion tool may become hot during use.

WARNING!

Danger of burns

•  when changing tools

•  when setting the device down
Chips and splinters must not be removed while the machine

is running.
Keep mains lead clear from working range of the machine.

Always lead the cable away behind you.
When working in walls ceiling, or fl oor, take care to avoid

electric cables and gas or waterpipes.
Clamp your workpiece with a clamping device. Unclamped

workpieces can cause severe injury and damage.
Always disconnect the plug from the socket before carrying

out any work on the machine.

SPECIFIED CONDITIONS OF USE

The screwdriver is suited for setting dry wall screws when

fi xing gypsum plaster boards to wood furring or metal

furring.
Do not use this product in any other way as stated for

normal use.

EC-DECLARATION OF CONFORMITY

We declare under our sole responsibility that the product

described under “Technical Data” fulfi lls all the relevant

provisions of the directives 2011/65/EU (RoHs), 2014/30/

EU, 2006/42/EC and the following harmonized standards

have been used:

WARNING

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given

in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for diff erent

applications, with diff erent accessories or poorly maintained, the vibration emission may diff er. This may signifi cantly increase

the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off  or

when it is running but not actually doing the job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eff ects of vibration such as: maintain the tool and the

accessories, keep the hands warm, organisation of work patterns.

SYMBOLS

CAUTION! WARNING! DANGER!

Always disconnect the plug from the socket

before carrying out any work on the machine.

Please read the instructions carefully before

starting the machine.

Do not dispose of electric tools together with

household waste material.

Electric tools and electronic equipment that

have reached the end of their life must be

collected separately and returned to an

environmentally compatible recycling facility.

Check with your local authority or retailer for

recycling advice and collection point.

Class II tool, tool in which protection against

electric shock does not rely on basic

insulation only, but in which additional safety

precautions, such as double insulation or

reinforced insulation, are provided.

There being no provision for protective

earthing or reliance upon installation

conditions.

European Conformity Mark

National mark of conformity Ukraine

EurAsian Conformity Mark.
