20

21

BTS18BL

.........................4589 56 01...

   ...000001-999999

....................... 0-5000 min

-1

............................. 4,2 mm

......................... 25-55 mm

............................. ± 5 mm

............................. ± 3 mm

................................ 5 Nm

....................1/4 ''HEX (6,35mm)

.............................. 18 V

............................. 1,7 kg

........................... 2,12 kg

........................... 73,5 dB (A)

........................... 84,5 dB (A)

.......................... < 2,5 m/s

2

............................. 1,5 m/s

2

TECHNICAL DATA

CORDLESS  SCREWDRIVER

Production code..................................................................................

No-load speed ....................................................................................

Screw diameter max. ..........................................................................

Screw lengths .....................................................................................

Setting range of depth gauge .............................................................

Setting range of depth gauge for autofeed attachment ......................

Torque max .........................................................................................

Universal reception .............................................................................

Battery voltage....................................................................................

Weight according EPTA-Procedure 01/2003 ......................................

Weight according EPTA-Procedure 01/2003 with autofeed attachment ...

Noise/vibration information

Measured values determined according to EN 60745.

Typically, the A-weighted noise levels of the tool are:

Sound pressure level (Uncertainty K=3dB(A)) ...................................

Sound power level (Uncertainty K=3dB(A)) ........................................

Always wear ear protectors!

Total vibration values (vector sum in the three axes) determined

according to EN 60745.

Vibration emission value a

h

  Screwing..........................................................................................

  Uncertainty K ...................................................................................

 WARNING Read all safety warnings, instructions,

illustrations and specifi cations provided with this power tool.

Failure to follow all instructions listed below may result in electric

shock, fi re and/or serious injury.

Save all warnings and

instructions for future reference.

SCREWDRIVER SAFETY WARNINGS

Hold the power tool by insulated gripping surfaces, when

performing an operation where the fastener may contact

hidden wiring.

 Fasteners contacting a "live" wire may make

exposed metal parts of the power tool "live" and could give the

operator an electric shock.

ADDITIONAL SAFETY AND WORKING INSTRUCTIONS

Use protective equipment. Always wear safety glasses when

working with the machine. The use of protective clothing is

recommended, such as dust mask, protective gloves, sturdy

non-slip footwear, helmet and ear defenders.
The dust produced when using this tool may be harmful to health.

Do not inhale the dust. Wear a suitable dust protection mask.
Do not machine any materials that present a danger to health (e.g.

asbestos).
Switch the device off  immediately if the insertion tool stalls! Do not

switch the device on again while the insertion tool is stalled, as

doing so could trigger a sudden recoil with a high reactive force.

Determine why the insertion tool stalled and rectify this, paying

heed to the safety instructions.
The possible causes may be:

•  it is tilted in the workpiece to be machined

•  it has pierced through the material to be machined

•  the power tool is overloaded
Do not reach into the machine while it is running.
The insertion tool may become hot during use.

•  when changing tools

•  when setting the device down

Gypsum plaster and splinters must not be removed while the

machine is running.
When working in walls ceiling, or fl oor, take care to avoid electric

cables and gas or waterpipes.
Clamp your workpiece with a clamping device. Unclamped

workpieces can cause severe injury and damage.
Remove the battery pack before starting any work on the machine.
Do not dispose of used battery packs in the household refuse or by

burning them. AEG Distributors off er to retrieve old batteries to

protect our environment.
Do not store the battery pack together with metal objects (short

circuit risk).
Use only System PCLS chargers for charging System PCLS

battery packs. Do not use battery packs from other systems.
Never break open battery packs and chargers and store only in dry

rooms. Keep dry at all times.
Battery acid may leak from damaged batteries under extreme load

or extreme temperatures. In case of contact with battery acid wash

it off  immediately with soap and water. In case of eye contact rinse

thoroughly for at least 10 minutes and immediately seek medical

attention.
Do not insert the bit on tool when the  tool is running, and switch is

lock on status, the bit will be run and may hurt the user

Warning!

To reduce the risk of fi re, personal injury, and product

damage due to a short circuit, never immerse your tool, battery

pack or charger in fl uid or al-low a fl uid to fl ow inside them.

Corrosive or conductive fl uids, such as seawater, certain industrial

chemicals, and bleach or bleach containing products, etc., Can

cause a short circuit.

SPECIFIED CONDITIONS OF USE

The screwdriver is suited for setting dry wall screws when fi xing

gypsum plaster boards to wood furring or metal furring.
Do not use this product in any other way as stated for normal use.

WARNING

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 60745

and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for diff erent applications, with

diff erent accessories or poorly maintained, the vibration emission may diff er. This may signifi cantly increase the exposure level over the total

working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off  or when it is running

but not actually doing the job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eff ects of vibration such as: maintain the tool and the accessories, keep

the hands warm, organisation of work patterns.

ENGLISH

EC-DECLARATION OF CONFORMITY

We declare under our sole responsibility that the product described

under “Technical Data” fulfi lls all the relevant regulations and the

directives 2011/65/EU (RoHs), 2014/30/EU, 2006/42/EC, and the

following harmonized standards have been used:
EN 60745-1:2009 + A11:2010

EN 60745-2-2:2010

EN 55014-1:2006 + A1:2009 + A2:2011

EN 55014-2:2015

EN 50581:2012
Winnenden, 2017-08-03

Alexander Krug

Managing Director
Authorized to compile the technical fi le.
Techtronic Industries GmbH

Max-Eyth-Straße 10

71364 Winnenden

Germany

BATTERIES

Battery packs which have not been used for some time should be

recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance

of the battery pack. Avoid extended exposure to heat or sunshine

(risk of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, after use, the battery packs have to be

fully charged.
To obtain the longest possible battery life remove the battery pack

from the charger once it is fully charged.
For battery pack storage longer than 30 days:

Store the battery pack where the temperature is below 27°C and

away from moisture

Store the battery packs in a 30% - 50% charged condition

Every six months of storage, charge the pack as normal.

BATTERY PACK PROTECTION

In extremely high torque, binding, stalling and short circuit

situations that cause high current draw, the tool will vibrate for

about 2 seconds and then the tool will turn OFF.

To reset, release the trigger.

Under extreme circumstances, the internal temperatur of the

battery could become to high. If this happens, the battery will shut

down.

Place the battery on the charger to charge and reset it.

TRANSPORTING LITHIUM BATTERIES

Lithium-ion batteries are subject to the Dangerous Goods

Legislation requirements.
Transportation of those batteries has to be done in accordance

with local, national and international provisions and regulations.
•  The user can transport the batteries by road without further

requirements.

•  Commercial transport of Lithium-Ion batteries by third parties is

subject to Dangerous Goods regulations. Transport preparation

and transport are exclusively to be carried out by appropriately

trained persons and the process has to be accompanied by

corresponding experts.

When transporting batteries:
•  Ensure that battery contact terminals are protected and insulated

to prevent short circuit.

•  Ensure that battery pack is secured against movement within

packaging.

•  Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice

MAINTENANCE

Use only AEG accessories and spare parts. Should components

need to be replaced which have not been described, please

contact one of our AEG service agents (see our list of guarantee/

service addresses).
If needed, an exploded view of the tool can be ordered. Please

state the machine type printed as well as the six-digit No. on the

label and order the drawing at your local service agents or directly

at: Techtronic Industries GmbH, Max-Eyth-Straße 10,

71364 Winnenden, Germany.

SYMBOLS

CAUTION! WARNING! DANGER!

Remove the battery pack before starting any work on

the machine.

Please read the instructions carefully before starting

the machine.

Magazine available as accessory.

Do not dispose electric tools, batteries/rechargeable

batteries together with household waste material.

Electric tools and batteries that have reached the end

of their life must be collected separately and returned

to an environmentally compatible recycling facility.

Check with your local authority or retailer for recycling

advice and collection point.

n0

No-load speed

V

Volts

Direct current

European Conformity Mark

National mark of conformity Ukraine

EurAsian Conformity Mark.

ENGLISH
