AEG BSS12C-0 4935446702 - Инструкция по эксплуатации - Страница 7

12

13

BSS 12 C

.........................1/4" (6,35  mm)

....................0-1800 min

-1

....................0-2400 min

-1

......................... 113 Nm

........................... 12 V

.......................... 1,2 kg

........................ 74,0 dB  (A)

........................ 85,0 dB  (A)

.......................... 4,3 m/s

2

.......................... 1,5 m/s

2

ENGLISH

TECHNICAL DATA

Cordless Impact Screwdriver

Tool reception ..........................................................................

No-load speed .........................................................................

Impact range............................................................................

Torque......................................................................................

Battery voltage.........................................................................

Weight according EPTA-Procedure 01/2003 (1,5 Ah) .............

Noise/vibration information

Measured values determined according to EN 60 745.

Typically, the A-weighted noise levels of the tool are:

  Sound  pressure  level  (K = 3 dB(A)) .......................................

  Sound  power  level  (K = 3 dB(A)) ............................................

Wear ear protectors!

Total vibration values (vector sum in the three axes)

determined according to EN 60745.

  Vibration emission value a

h

 ..................................................

  Uncertainty K= ......................................................................

WARNING! Read all safety warnings and all

instructions, including those given in the accompanying

brochure.

 Failure to follow the warnings and instructions

may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

SAFETY INSTRUCTIONS

Wear ear protectors.

 Exposure to noise can cause hearing

loss.

Hold power tool by insulated gripping surfaces, when

performing an operation where the fastener may

contact hidden wiring.

Fasteners contacting a „live“ wire

may make exposed metal parts of the power tool „live“ and

could give the operator an electric shock.

Sawdust and splinters must not be removed while the

machine is running.

When working in walls ceiling, or floor, take care to avoid

electric cables and gas or waterpipes.

Remove the battery pack before starting any work on the

machine.

Do not dispose of used battery packs in the household

refuse or by burning them. AEG Distributors offer to retrieve

old batteries to protect our environment.

Do not store the battery pack together with metal objects

(short circuit risk).

Use only System PCLS chargers for charging System PCLS

battery packs. Do not use battery packs from other systems.

Battery acid may leak from damaged batteries under

extreme load or extreme temperatures. In case of contact

with battery acid wash it off immediately with soap and

water. In case of eye contact rinse thoroughly for at least 10

minutes and immediately seek medical attention.

SPECIFIED CONDITIONS OF USE

The cordless impact driver can be used to tighten and

loosen nuts and bolts wherever no mains connection is

available.

Do not use this product in any other way as stated for

normal use.

EC-DECLARATION OF CONFORMITY

We declare under our sole responsibility that this product is

in conformity with the following standards or standardized

documents.

EN 60745-1:2009 + A11:2010

EN 60745-2-2:2010

EN 55014-1:2006 + A1:2009 + A2:2011

EN 55014-2:1997 + A1:2001 + A2:2008

in accordance with the regulations

2011/65/EU (RoHs)

2006/42/EC

2004/108/EC

Winnenden, 2012-09-11

Rainer Kumpf

Director Product Development

Authorized to compile the technical file

BATTERIES

New battery packs reach full loading capacity after 4 - 5

chargings and dischargings. Battery packs which have not

been used for some time should be recharged before use.

Temperatures in excess of 50°C (122°F) reduce the

performance of the battery pack. Avoid extended exposure

to heat or sunshine (risk of overheating).

The contacts of chargers and battery packs must be kept

clean.

WARNING

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given

in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.

The declared vibration emission level represents the main applications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained, the vibration emission may differ. This may significantly increase

the exposure level over the total working period.

An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may significantly reduce the exposure level over the total working period.

Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the

accessories, keep the hands warm, organisation of work patterns.

ENGLISH

For an optimum life-time, after use, the battery packs have

to be fully charged.

To obtain the longest possible battery life remove the battery

pack from the charger once it is fully charged.

For battery pack storage longer than 30 days:

Store the battery pack where the temperature is below 27°C

and away from moisture

Store the battery packs in a 30% - 50% charged condition

Every six months of storage, charge the pack as normal.

BATTERY PACK PROTECTION

The battery pack has overload protection that protects it

from being overloaded and helps to ensure long life.

Under extreme stress the battery electronics switch off the

machine automatically. To restart, switch the machine off

and then on again. If the machine does not start up again,

the battery pack may have discharged completely. In this

case it must be recharged in the battery charger.

MAINTENANCE

Use only AEG accessories and spare parts. Should

components need to be replaced which have not been

described, please contact one of our AEG service agents

(see our list of guarantee/service addresses).

If needed, an exploded view of the tool can be ordered.

Please state the Article No. as well as the machine type

printed on the label and order the drawing at your local

service agents or directly at: AEG Electric Tools,

Max-Eyth-Straße 10, D-71364 Winnenden, Germany.

SYMBOLS

Please read the instructions carefully before

starting the machine.

Remove the battery pack before starting any

work on the machine.

Do not dispose of electric tools together with

household waste material! In observance of

European Directive 2002/96/EC on waste

electrical and electronic equipment and its

implementation in accordance with national law,

electric tools that have reached the end of their

life must be collected separately and returned to

an environmentally compatible recycling facility.

BSS 12 C

.........................1/4" (6,35  mm)

....................0-1800 min

-1

....................0-2400 min

-1

......................... 113 Nm

........................... 12 V

.......................... 1.2 kg

........................ 74.0 dB  (A)

........................ 85.0 dB  (A)

.......................... 4.3 m/s

2

.......................... 1.5 m/s

2
