AEG BSS 18C-0 428405 - Инструкция по эксплуатации - Страница 8

14

15

BSS 18C

..................... 4408 84 01...

..................... 4471 89 01...

   ...000001-999999

.........................1/4" (6,35 mm)

....................0-2400 min

-1

....................0-3100 min

-1

......................... 180 Nm

......................... 190 Nm

........................ M14

........................... 18 V

........................ 1,56 kg

........................ 1,81 kg

........................ 89,5 dB (A)

...................... 100,5 dB (A)

.......................... 2,5 m/s

2

.......................... 1,5 m/s

2

ENGLISH

SPECIFIED CONDITIONS OF USE

The cordless impact wrench can be used to tighten and

loosen nuts and bolts wherever no mains connection is

available.
Do not use this product in any other way as stated for

normal use.

EC-DECLARATION OF CONFORMITY

We declare under our sole responsibility that the product

described under “Technical Data” fulfi lls all the relevant

regulations and the directives 2011/65/EU (RoHs),

2006/42/EC, 2004/108/EC and the following harmonized

standards have been used:
EN 60745-1:2009 + A11:2010

EN 60745-2-2:2010

EN 55014-1:2006 + A1:2009 + A2:2011

EN 55014-2:1997 + A1:2001 + A2:2008

EN 50581:2012

Winnenden, 2014-11-20

Alexander Krug

Managing Director
Authorized to compile the technical fi le.
Techtronic Industries GmbH

Max-Eyth-Straße 10

71364 Winnenden

Germany

BATTERIES

Battery packs which have not been used for some time

should be recharged before use.
Temperatures in excess of 50°C (122°F) reduce the

performance of the battery pack. Avoid extended exposure

to heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept

clean.
For an optimum life-time, the battery packs have to be fully

charged, after used.
To obtain the longest possible battery life remove the battery

pack from the charger once it is fully charged.
For battery pack storage longer than 30 days:

Store the battery pack where the temperature is below 27°C

and away from moisture

Store the battery packs in a 30% - 50% charged condition

Every six months of storage, charge the pack as normal.

BATTERY PACK PROTECTION LI-ION BATTERY

The battery pack has overload protection that protects it

from being overloaded and helps to ensure long life.

Under extreme stress the battery electronics switch off the

machine automatically. To restart, switch the machine off

and then on again. If the machine does not start up again,

the battery pack may have discharged completely. In this

case it must be recharged in the battery charger.

MAINTENANCE

Use only AEG accessories and spare parts. Should

components need to be replaced which have not been

described, please contact one of our AEG service agents

(see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.

Please state the machine type printed as well as the six-digit

No. on the label and order the drawing at your local service

agents or directly at: Techtronic Industries GmbH,

Max-Eyth-Straße 10, 71364 Winnenden, Germany.

SYMBOLS

CAUTION! WARNING! DANGER!

Remove the battery pack before starting any

work on the machine.

Please read the instructions carefully before

starting the machine.

Do not dispose of electric tools together with

household waste material.

Electric tools and electronic equipment that

have reached the end of their life must be

collected separately and returned to an

environmentally compatible recycling facility.

Check with your local authority or retailer for

recycling advice and collection point.

European Conformity Mark

EurAsian Conformity  Mark.

ENGLISH

TECHNICAL DATA

Cordless Impact Screwdriver

Production code.......................................................................

   ..............................................................................................

Tool reception ..........................................................................

No-load speed .........................................................................

Impact range............................................................................

Torque (1.5 Ah) ........................................................................

Torque (3.0 Ah) ........................................................................

Max. diameter bolt / nut ...........................................................

Battery voltage.........................................................................

Weight according EPTA-Procedure 01/2003 (1,5 Ah) .............

Weight according EPTA-Procedure 01/2003 (3,0 Ah) .............

Noise/vibration information

Measured values determined according to EN 60 745.

Typically, the A-weighted noise levels of the tool are:

Sound pressure level (Uncertainty K=3dB(A)) ........................

Sound power level (Uncertainty K=3dB(A)) .............................

Wear ear protectors!

Total vibration values (vector sum in the three axes)

determined according to EN 60745.

Vibration emission value a

h

  Impact tightening of fasteners of the maximum capacity of the tool .

  Uncertainty K= ......................................................................

 WARNING! Read all safety warnings and all

instructions.

Failure to follow the warnings and instructions

may result in electric shock, fi re and/or serious injury.

Save all warnings and instructions for future reference.

Impact driver SAFETY WARNINGS

Hold power tool by insulated gripping surfaces, when

performing an operation where the fastener may

contact hidden wiring.

Fasteners contacting a „live“ wire

may make exposed metal parts of the power tool „live“ and

could give the operator an electric shock.

Wear ear protectors.

 Exposure to noise can cause hearing

loss.

Additional Safety and Working Instructions

Use protective equipment. Always wear safety glasses when

working with the machine. The use of protective clothing is

recommended, such as dust mask, protective gloves, sturdy

non-slip footwear, helmet and ear defenders.
The dust produced when using this tool may be harmful to

health. Do not inhale the dust. Wear a suitable dust

protection mask.
Do not machine any materials that present a danger to

health (e.g. asbestos).
Switch the device off immediately if the insertion tool stalls!

Do not switch the device on again while the insertion tool is

stalled, as doing so could trigger a sudden recoil with a high

reactive force. Determine why the insertion tool stalled and

rectify this, paying heed to the safety instructions.
The possible causes may be:

•  it is tilted in the workpiece to be machined

•  it has pierced through the material to be machined

•  the power tool is overloaded
Do not reach into the machine while it is running.

The insertion tool may become hot during use.

•  when changing tools

•  when setting the device down
Sawdust and splinters must not be removed while the

machine is running.
When working in walls ceiling, or fl oor, take care to avoid

electric cables and gas or waterpipes.
Clamp your workpiece with a clamping device. Unclamped

workpieces can cause severe injury and damage.
Remove the battery pack before starting any work on the

machine.
Do not dispose of used battery packs in the household

refuse or by burning them. AEG Distributors offer to retrieve

old batteries to protect our environment.
Do not store the battery pack together with metal objects

(short circuit risk).
Use only System PCLS chargers for charging System PCLS

battery packs. Do not use battery packs from other systems.
Never break open battery packs and chargers and store

only in dry rooms. Keep dry at all times.
Battery acid may leak from damaged batteries under

extreme load or extreme temperatures. In case of contact

with battery acid wash it off immediately with soap and

water. In case of eye contact rinse thoroughly for at least 10

minutes and immediately seek medical attention.

WARNING

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given

in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained, the vibration emission may differ. This may signifi cantly increase

the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the

accessories, keep the hands warm, organisation of work patterns.
