18

19

BS18G3

BSB18G3

................................... 4678 52 01...    ............................. 4678 59 01...

   ...000001-999999

   ...000001-999999

........................................ 13 mm .......................................... 13 mm

........................................ 40 mm .......................................... 40 mm

........................................... -  ................................................ 13 mm

.......................................... 6 mm ............................................ 6 mm

................................... 0-500 min

-1

 ................................... 0-500 min

-1

................................. 0-1850 min

-1

 ................................. 0-1850 min

-1

........................................... -  .......................................... 24050 min

-1

........................................ 55 Nm .......................................... 55 Nm

........................................ 55 Nm .......................................... 55 Nm

........................................ 60 Nm .......................................... 60 Nm

........................................ 18 V ............................................. 18 V

.................................. 2,0-13 mm .................................... 2,0-13 mm

....................................... 1,3 kg ........................................... 1,3 kg

....................................... 1,7 kg ........................................... 1,8 kg

....................................... 1,8 kg ........................................... 1,8 kg

....................................... 2,0 kg ........................................... 2,1 kg

.............................. -18...+50 °C .................................. -18...+50 °C

................................................ L1840R, L1830R, L1820R, L1815R

...................................................................... BL1218

........................................ 81 dB (A)...................................... 81 dB (A)

........................................ 92 dB (A)...................................... 92 dB (A)

........................................... -  ............................................ < 2,5 m/s

2

........................................... -  ............................................... 1,5 m/s

2

.................................... < 2,5 m/s

2

 ..................................... < 2,5 m/s

2

....................................... 1,5 m/s

2

 ........................................ 1,5 m/s

2

.................................... < 2,5 m/s

2

 ..................................... < 2,5 m/s

2

....................................... 1,5 m/s

2

 ........................................ 1,5 m/s

2

ENGLISH

ENGLISH

Do not dispose of used battery packs in the household refuse or by burning them.

AEG Distributors off er to retrieve old batteries to protect our environment.
Do not store the battery pack together with metal objects (short circuit risk).
Use only System BGS chargers for charging System BGS battery packs. Do not use

battery packs from other systems.
Never break open battery packs and chargers and store only in dry rooms. Keep dry

at all times.
Battery acid may leak from damaged batteries under extreme load or extreme

temperatures. In case of contact with battery acid wash it off  immediately with soap

and water. In case of eye contact rinse thoroughly for at least 10 minutes and

immediately seek medical attention.

Warning!

To reduce the risk of fi re, personal injury, and product damage due to a

short circuit, never immerse your tool, battery pack or charger in fl uid or al-low a fl uid

to fl ow inside them. Corrosive or conductive fl uids, such as seawater, certain industrial

chemicals, and bleach or bleach containing products, etc., Can cause a short circuit.

SPECIFIED CONDITIONS OF USE

BS18G3:

The electronic battery drill/screwdriver may be used for drilling, as well as

screwdriving for independent use away from mains supply.

BSB18G3:

The electronic battery percussion drill/screwdriver may be used for drilling,

percussion drilling, as well as screwdriving for independent use away from mains

supply.
Do not use this product in any other way as stated for normal use.

EC-DECLARATION OF CONFORMITY

We declare under our sole responsibility that the product  described under “Technical

Data” fulfi lls all the relevant provisions of the directives 2011/65/EU (RoHS), 2014/30/

EU, 2006/42/EC and the following harmonized standards have been used:
EN 60745-1: 2009 + A11: 2010

EN 60745-2-1: 2010

EN 60745-2-2: 2010

EN 55014-1:2017

EN 55014-2:2015

EN 50581:2012
Winnenden, 2018-06-14

Alexander Krug

Managing Director
Authorized to compile the technical fi le.
Techtronic Industries GmbH

Max-Eyth-Straße 10

71364 Winnenden

Germany

BATTERIES

Battery packs which have not been used for some time should be recharged before

use.
Temperatures in excess of 50°C (122°F) reduce the performance of the battery pack.

Avoid extended exposure to heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged, after used.
To obtain the longest possible battery life remove the battery pack from the charger

once it is fully charged.
For battery pack storage longer than 30 days:

Store the battery pack where the temperature is below 27°C and away from moisture

Store the battery packs in a 30% - 50% charged condition

Every six months of storage, charge the pack as normal.

BATTERY PACK PROTECTION LI-ION BATTERY

The battery pack has overload protection that protects it from being overloaded and

helps to ensure long life.

Under extreme stress the battery electronics switch off  the machine automatically. To

restart, switch the machine off  and then on again. If the machine does not start up

again, the battery pack may have discharged completely. In this case it must be

recharged in the battery charger.

TRANSPORTING LITHIUM BATTERIES

Lithium-ion batteries are subject to the Dangerous Goods Legislation requirements.
Transportation of those batteries has to be done in accordance with local, national and

international provisions and regulations.
•  The user can transport the batteries by road without further

requirements.

•  Commercial transport of Lithium-Ion batteries by third parties is

subject to Dangerous Goods regulations. Transport preparation and

transport are exclusively to be carried out by appropriately trained

persons and the process has to be accompanied by corresponding

experts.

When transporting batteries:
•  Ensure that battery contact terminals are protected and insulated to

prevent short circuit.

•  Ensure that battery pack is secured against movement within

packaging.

•  Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice

MAINTENANCE

Use only AEG accessories and spare parts. Should components need to be replaced

which have not been described, please contact one of our AEG service agents (see

our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please state the machine type

printed as well as the six-digit No. on the label and order the drawing at your local

service agents or directly at: Techtronic Industries GmbH, Max-Eyth-Straße 10,

71364 Winnenden, Germany.

SYMBOLS

CAUTION! WARNING! DANGER!

Remove the battery pack before starting any work on the machine.

Please read the instructions carefully before starting the machine.

Do not dispose electric tools, batteries/rechargeable

batteries together with household waste material.

Electric tools and batteries that have reached the end

of their life must be collected separately and returned

to an environmentally compatible recycling facility.

Check with your local authority or retailer for recycling

advice and collection point.

n

0

No-load speed

n

Impacts

V

Volts

Direct current

European Conformity Mark

Ukraine Conformity Mark

EurAsian Conformity Mark

TECHNICAL DATA

CORDLESS PERCUSSION DRILL/DRIVER

Production code................................................................................................................

Drilling capacity in steel ....................................................................................................

Drilling capacity in wood ...................................................................................................

Drilling capacity in brick and tile .......................................................................................

Wood screws (without pre-drilling) ...................................................................................

No-load speed 1st gear ....................................................................................................

No-load speed 2nd gear ...................................................................................................

Rate of percussion under load max. .................................................................................

Torque with battery (1.5 Ah Li-Ion) *1  ..............................................................................

Torque with battery (2.0 Ah Li-Ion) *1  ..............................................................................

Torque with battery (4.0 Ah Li-Ion) *1  ..............................................................................

Battery voltage..................................................................................................................

Drill chuck range ...............................................................................................................

Weight without battery

 ......................................................................................................

Weight according EPTA-Procedure 01/2014 (1.5 Ah Li-Ion) ............................................

Weight according EPTA-Procedure 01/2014 (2.0 Ah Li-Ion) ............................................

Weight according EPTA-Procedure 01/2014 (4.0 Ah Li-Ion) ............................................

Recommended ambient operating temperature ...............................................................

Recommended battery types............................................................................................

Recommended charger

 ....................................................................................................

Noise/vibration information

Measured values determined according to EN 60745.

Typically, the A-weighted noise levels of the tool are:

Sound pressure level (Uncertainty K=3dB(A)) .................................................................

Sound power level (Uncertainty K=3dB(A)) ......................................................................

Wear ear protectors!

Total vibration values (vector sum in the three axes) determined according to

EN 60745.

Vibration emission value a

h

  Impact drilling into concrete ..........................................................................................

  Uncertainty K= ..............................................................................................................

  Drilling into metal ..........................................................................................................

  Uncertainty K= ..............................................................................................................

  Screwing .......................................................................................................................

  Uncertainty K= ..............................................................................................................

*1 Measured according to AEG Standard N 877318

 WARNING Read all safety warnings, instructions,

illustrations and specifi cations provided with this power tool.

Failure to follow all instructions listed below may result in electric

shock, fi re and/or serious injury.

Save all warnings and

instructions for future reference.

 DRILL SAFETY WARNINGS

Wear ear protectors when impact drilling.

Exposure to noise can cause hearing

loss.

Hold the power tool by insulated gripping surfaces, when performing an

operation where the cutting accessory may contact hidden wiring.

Cutting accessory contacting a „live“ wire may make exposed metal parts of the power

tool „live“ and could give the operator an electric shock.

Never operate at higher speed than the maximum speed rated of the drill bit.

At

higher speeds, the bit is likely to bend if allowed to rotate freely without contacting the

workpiece, resulting the personal injury.

Always start drilling at low speed and with the bit tip in contact with the

workpiece.

At higher speeds, the bit is likely to bend if allowed to rotate freely without

contacting the workpiece, resulting the personal injury.

Apply pressure only in direct line with the bit and do not apply excessive

pressure.

Bits can bend causing breakage or loss of control, resulting in personal

injury.

SCREWDRIVER SAFETY WARNINGS

Hold the power tool by insulated gripping surfaces, when performing an

operation where the fastener may contact hidden wiring.

Fasteners contacting a

"live" wire may make exposed metal parts of the power tool "live" and could give the

operator an electric shock.

ADDITIONAL SAFETY AND WORKING INSTRUCTIONS

Use protective equipment. Always wear safety glasses when working with the

machine. The use of protective clothing is recommended, such as dust mask,

protective gloves, sturdy non-slip footwear, helmet and ear defenders.
The dust produced when using this tool may be harmful to health. Do not inhale the

dust. Wear a suitable dust protection mask.
Do not machine any materials that present a danger to health (e.g. asbestos).
Switch the device off  immediately if the insertion tool stalls! Do not switch the device

on again while the insertion tool is stalled, as doing so could trigger a sudden recoil

with a high reactive force. Determine why the insertion tool stalled and rectify this,

paying heed to the safety instructions.
The possible causes may be:

•  it is tilted in the workpiece to be machined

•  it has pierced through the material to be machined

•  the power tool is overloaded
Do not reach into the machine while it is running.
The insertion tool may become hot during use.

WARNING!

Danger of burns

•  when changing tools

•  when setting the device down
Chips and splinters must not be removed while the machine is running.
When working in walls ceiling, or fl oor, take care to avoid electric cables and gas or

waterpipes.
Clamp your workpiece with a clamping device. Unclamped workpieces can cause

severe injury and damage.
Remove the battery pack before starting any work on the machine.

WARNING

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 60745 and may be used to compare one tool with

another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for diff erent applications, with diff erent accessories or poorly

maintained, the vibration emission may diff er. This may signifi cantly increase the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off  or when it is running but not actually doing the job. This may

signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eff ects of vibration such as: maintain the tool and the accessories, keep the hands warm, organisation of work

patterns.
