BSB12 G3

BSB14 G3

..... 4566 14 02...    .............4566 20 02...

   ...000001-999999     ...000001-999999

..............10 mm .................. 13 mm

..............30 mm .................. 32 mm

................5 mm .................... 5 mm

..............10 mm .................. 10 mm

............350 min

-1

 .............. 400  min

-1

..........1500 min

-1

 ............ 1700 min

-1

..............32 Nm .................. 36 Nm

..............12 V .................. 14,4 V

....... 0,8-10 mm ............ 2,0-13 mm

...........1,17 kg ................. 1,26 kg

...........84,5 dB (A) .......... 86,5 dB (A)

...........95,5 dB (A) .......... 97,5 dB (A)

.............9,3 m/s

2

 ................ 9,4 m/s

2

.............1,5 m/s

2

 ................ 1,5 m/s

2

.............0,7 m/s

2

 ................ 2,0 m/s

2

.............1,5 m/s

2

 ................ 1,5 m/s

2

.............0,5 m/s

2

 ................ 1,2 m/s

2

.............1,5 m/s

2

 ................ 1,5 m/s

22

ENGLISH

Use only AL1214G3 chargers for charging System L1215G3,

L1220G3, L1415G3 and L1420G3  battery packs. Do not use battery

packs from other systems.
Never break open battery packs and chargers and store only in dry

rooms. Keep dry at all times.
Battery acid may leak from damaged batteries under extreme load or

extreme temperatures. In case of contact with battery acid wash it off

immediately with soap and water. In case of eye contact rinse

thoroughly for at least 10 minutes and immediately seek medical

attention.

Warning!

To reduce the risk of fi re, personal injury, and product

damage due to a short circuit, never immerse your tool, battery pack or

charger in fl uid or al-low a fl uid to fl ow inside them. Corrosive or

conductive fl uids, such as seawater, certain industrial chemicals, and

bleach or bleach containing products, etc., Can cause a short circuit.

SPECIFIED CONDITIONS OF USE

The battery percussion drill/screwdriver may be used for drilling,

percussion drilling, as well as screwdriving for independent use away

from mains supply.
Do not use this product in any other way as stated for normal use.

EC-DECLARATION OF CONFORMITY

We declare under our sole responsibility that the product  described

under “Technical Data” fulfi lls all the relevant provisions of the

directives 2011/65/EU (RoHs), 2014/30/EU, 2006/42/EC and the

following harmonized standards have been used:
EN 60745-1:2009 + A11:2010

EN 60745-2-1:2010

EN 60745-2-2:2010

EN 55014-1:2006 + A1:2009 + A2:2011

EN 55014-2:2015

EN 50581:2012

Winnenden, 2017-09-25

Alexander Krug

Managing Director
Authorized to compile the technical fi le.
Techtronic Industries GmbH

Max-Eyth-Straße 10

71364 Winnenden

Germany

BATTERIES

Battery packs which have not been used for some time should be

recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance of

the battery pack. Avoid extended exposure to heat or sunshine (risk of

overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged,

after used.
To obtain the longest possible battery life remove the battery pack from

the charger once it is fully charged.
For battery pack storage longer than 30 days:

Store the battery pack where the temperature is below 27°C and away

from moisture

Store the battery packs in a 30% - 50% charged condition

Every six months of storage, charge the pack as normal.

BATTERY PACK PROTECTION LI-ION BATTERY

The battery pack has overload protection that protects it from being

overloaded and helps to ensure long life.

Under extreme stress the battery electronics switch off  the machine

automatically. To restart, switch the machine off  and then on again. If

the machine does not start up again, the battery pack may have

discharged completely. In this case it must be recharged in the battery

charger.

TRANSPORTING LITHIUM BATTERIES

Lithium-ion batteries are subject to the Dangerous Goods Legislation

requirements.
Transportation of those batteries has to be done in accordance with

local, national and international provisions and regulations.
•  The user can transport the batteries by road without further

requirements.

•  Commercial transport of Lithium-Ion batteries by third parties is

subject to Dangerous Goods regulations. Transport preparation and

transport are exclusively to be carried out by appropriately trained

persons and the process has to be accompanied by corresponding

experts.

When transporting batteries:
•  Ensure that battery contact terminals are protected and insulated to

prevent short circuit.

•  Ensure that battery pack is secured against movement within

packaging.

•  Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice

MAINTENANCE

Use only AEG accessories and spare parts. Should components need

to be replaced which have not been described, please contact one of

our AEG service agents (see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please state

the machine type printed as well as the six-digit No. on the label and

order the drawing at your local service agents or directly at: Techtronic

Industries GmbH, Max-Eyth-Straße 10, 71364 Winnenden, Germany.

SYMBOLS

CAUTION! WARNING! DANGER!

Remove the battery pack before starting any work on

the machine.

Please read the instructions carefully before starting

the machine.

Do not dispose electric tools, batteries/

rechargeable batteries together with household

waste material.

Electric tools and batteries that have reached

the end of their life must be collected separately

and returned to an environmentally compatible

recycling facility.

Check with your local authority or retailer for

recycling advice and collection point.

European Conformity Mark

National mark of conformity Ukraine

EurAsian Conformity Mark.

ENGLISH

TECHNICAL DATA  CORDLESS PERCUSSION DRILL/DRIVER

Production code........................................................................................

Drilling capacity in steel ............................................................................

Drilling capacity in wood ...........................................................................

Wood screws (without pre-drilling) ...........................................................

Drilling capacity in brick and tile ...............................................................

No-load speed 1st gear ............................................................................

No-load speed 2nd gear ...........................................................................

Torque ......................................................................................................

Battery voltage..........................................................................................

Drill chuck range .......................................................................................

Weight according EPTA-Procedure 01/2003 (2.0 Ah) ..............................

Noise/vibration information

Measured values determined according to EN 60 745.

Typically, the A-weighted noise levels of the tool are:

Sound pressure level (Uncertainty K=3dB(A)) .........................................

Sound power level (Uncertainty K=3dB(A)) ..............................................

Wear ear protectors!

Total vibration values (vector sum in the three axes) determined

according to EN 60745.

Vibration emission value

  Impact drilling into concrete a

h.ID

 ...........................................................

  Uncertainty K= ......................................................................................

  Drilling into metal a

h.D

 ............................................................................

  Uncertainty K= ......................................................................................

  Screwing a

h

 ...........................................................................................

  Uncertainty K= ......................................................................................

 WARNING! Read all safety warnings and all instructions.

Failure to follow the warnings and instructions may result in electric

shock, fi re and/or serious injury.

Save all warnings and instructions for future reference.

DRILL SAFETY WARNINGS

Wear ear protectors when impact drilling.

Exposure to noise can

cause hearing loss.

Use auxiliary handle(s), if supplied with the tool.

 Loss of control

can cause personal injury.

Hold power tool by insulated gripping surfaces, when performing

an operation where the cutting accessory may contact hidden

wiring.

Cutting accessory contacting a „live“ wire may make exposed metal

parts of the power tool „live“ and could give the operator an electric

shock.

SCREWDRIVER SAFETY WARNINGS

Hold power tool by insulated gripping surfaces, when performing

an operation where the fastener may contact hidden wiring.

Fasteners contacting a "live" wire may make exposed metal parts of

the power tool "live" and could give the operator an electric shock.

ADDITIONAL SAFETY AND WORKING INSTRUCTIONS

Use protective equipment. Always wear safety glasses when working

with the machine. The use of protective clothing is recommended, such

as dust mask, protective gloves, sturdy non-slip footwear, helmet and

ear defenders.
The dust produced when using this tool may be harmful to health. Do

not inhale the dust. Wear a suitable dust protection mask.

Do not machine any materials that present a danger to health (e.g.

asbestos).
Switch the device off  immediately if the insertion tool stalls! Do not

switch the device on again while the insertion tool is stalled, as doing

so could trigger a sudden recoil with a high reactive force. Determine

why the insertion tool stalled and rectify this, paying heed to the safety

instructions.
The possible causes may be:

•  it is tilted in the workpiece to be machined

•  it has pierced through the material to be machined

•  the power tool is overloaded
Do not reach into the machine while it is running.
The insertion tool may become hot during use.

WARNING!

Danger of burns

•  when changing tools

•  when setting the device down
Chips and splinters must not be removed while the machine is running.
When working in walls ceiling, or fl oor, take care to avoid electric

cables and gas or waterpipes.
Clamp your workpiece with a clamping device. Unclamped workpieces

can cause severe injury and damage.
Remove the battery pack before starting any work on the machine.
Do not dispose of used battery packs in the household refuse or by

burning them. AEG Distributors off er to retrieve old batteries to protect

our environment.
Do not store the battery pack together with metal objects (short circuit

risk).

WARNING

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 60745 and may

be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for diff erent applications, with diff erent

accessories or poorly maintained, the vibration emission may diff er. This may signifi cantly increase the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off  or when it is running but not

actually doing the job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eff ects of vibration such as: maintain the tool and the accessories, keep the

hands warm, organisation of work patterns.
