16

17

BS12 G3

BS12 G3

BS14 G3

BS14 G3

BS14 G3

  Li-Ion 1,5 Ah

Li-Ion 2,0 Ah

Li-Ion 1,5 Ah

Li-Ion 1,5 Ah

Li-Ion 2,0 Ah

......4522 58 02...    .............. 4521 87 02...    ...............4523 02 02...    ...............4569 84 02...    ................4521 89 02...

   ...000001-999999 ........   ...000001-999999.......   ...000001-999999 ....    .   ...000001-999999 ....... ..000001-999999

........ 10 mm ................. 10 mm ..................10 mm ..................10 mm ................. 13 mm

........ 30 mm ................. 30 mm ..................30 mm ..................30 mm ................. 32 mm

.......... 5 mm ................... 5 mm ....................5 mm ....................5 mm ................... 5 mm

...... 350 min

-1

 ............. 350 min

-1

 ..............400 min

-1

 ..............400 min

-1

 .............. 400 min

-1

.... 1500 min

-1

 ........... 1500 min

-1

 ............1700 min

-1

 ............1700 min

-1

 ............ 1700 min

-1

........ 30 Nm ................. 32 Nm ..................32 Nm ..................32 Nm .................. 36 Nm

........ 12 V .................... 12 V ..................14,4 V ..................14,4 V .................. 14,4 V

.. 0,8-10 mm ........... 0,8-10 mm ........... 0,8-10 mm ............2,0-13 mm ...........2,0-13 mm

....... 1,1 kg .................. 1,1 kg ...................1,2 kg ...................1,2 kg ................... 1,2 kg

..... 84,5 dB (A) .......... 84,5 dB (A)...........86,5 dB (A) ..........86,5 dB (A) .......... 86,5 dB (A)

..... 95,5 dB (A) .......... 95,5 dB (A)...........97,5 dB (A) ..........97,5 dB (A) .......... 97,5 dB (A)

....... 0,5 m/s

2

 ............... 0,5 m/s

2

 ................1,2 m/s

2

 ................1,2 m/s

2

 ............... 1,2 m/s

2

....... 1,5 m/s

2

 ............... 1,5 m/s

2

 ................1,5 m/s

2

 ................1,5 m/s

2

 ............... 1,5 m/s

2

....... 0,7 m/s

2

 ............... 0,7 m/s

2

 ................2,0 m/s

2

 ................2,0 m/s

2

 ............... 2,0 m/s

2

....... 1,5 m/s

2

 ............... 1,5 m/s

2

 ................1,5 m/s

2

 ................1,5 m/s

2

 ............... 1,5 m/s

2

ENGLISH

Use only AL1214G3 chargers for charging System L1215G3,

L1220G3, L1415G3 and L1420G3  battery packs. Do not use

battery packs from other systems.
Never break open battery packs and chargers and store only in dry

rooms. Keep dry at all times.
Battery acid may leak from damaged batteries under extreme load

or extreme temperatures. In case of contact with battery acid wash

it off  immediately with soap and water. In case of eye contact rinse

thoroughly for at least 10 minutes and immediately seek medical

attention.

Warning!

To reduce the risk of fi re, personal injury, and product

damage due to a short circuit, never immerse your tool, battery

pack or charger in fl uid or al-low a fl uid to fl ow inside them.

Corrosive or conductive fl uids, such as seawater, certain industrial

chemicals, and bleach or bleach containing products, etc., Can

cause a short circuit.

SPECIFIED CONDITIONS OF USE

The battery drill/screwdriver is designed for drilling and

screwdriving for independent use away from mains supply.
Do not use this product in any other way as stated for normal use.

EC-DECLARATION OF CONFORMITY

We declare under our sole responsibility that the product

described under “Technical Data” fulfi lls all the relevant provisions

of the directives 2011/65/EU (RoHs), 2014/30/EU, 2006/42/EC and

the following harmonized standards have been used:
EN 60745-1:2009 + A11:2010

EN 60745-2-1:2010

EN 60745-2-2:2010

EN 55014-1:2006 + A1:2009 + A2:2011

EN 55014-2:2015

EN 50581:2012

Winnenden, 2017-09-25

Alexander Krug

Managing Director
Authorized to compile the technical fi le.
Techtronic Industries GmbH

Max-Eyth-Straße 10

71364 Winnenden

Germany

BATTERIES

Battery packs which have not been used for some time should be

recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance

of the battery pack. Avoid extended exposure to heat or sunshine

(risk of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully

charged, after used.
To obtain the longest possible battery life remove the battery pack

from the charger once it is fully charged.
For battery pack storage longer than 30 days:

Store the battery pack where the temperature is below 27°C and

away from moisture

Store the battery packs in a 30% - 50% charged condition

Every six months of storage, charge the pack as normal.

BATTERY PACK PROTECTION LI-ION BATTERY

The battery pack has overload protection that protects it from being

overloaded and helps to ensure long life.

Under extreme stress the battery electronics switch off  the

machine automatically. To restart, switch the machine off  and then

on again. If the machine does not start up again, the battery pack

may have discharged completely. In this case it must be recharged

in the battery charger.

TRANSPORTING LITHIUM BATTERIES

Lithium-ion batteries are subject to the Dangerous Goods

Legislation requirements.
Transportation of those batteries has to be done in accordance

with local, national and international provisions and regulations.
•  The user can transport the batteries by road without further

requirements.

•  Commercial transport of Lithium-Ion batteries by third parties is

subject to Dangerous Goods regulations. Transport preparation

and transport are exclusively to be carried out by appropriately

trained persons and the process has to be accompanied by

corresponding experts.

When transporting batteries:
•  Ensure that battery contact terminals are protected and insulated

to prevent short circuit.

•  Ensure that battery pack is secured against movement within

packaging.

•  Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice

MAINTENANCE

Use only AEG accessories and spare parts. Should components

need to be replaced which have not been described, please

contact one of our AEG service agents (see our list of guarantee/

service addresses).
If needed, an exploded view of the tool can be ordered. Please

state the machine type printed as well as the six-digit No. on the

label and order the drawing at your local service agents or directly

at: Techtronic Industries GmbH, Max-Eyth-Straße 10,

71364 Winnenden, Germany.

SYMBOLS

CAUTION! WARNING! DANGER!

Remove the battery pack before starting any work

on the machine.

Please read the instructions carefully before

starting the machine.

Do not dispose electric tools, batteries/

rechargeable batteries together with household

waste material.

Electric tools and batteries that have reached

the end of their life must be collected separately

and returned to an environmentally compatible

recycling facility.

Check with your local authority or retailer for

recycling advice and collection point.

European Conformity Mark

National mark of conformity Ukraine

EurAsian Conformity Mark.

ENGLISH

TECHNICAL DATA

CORDLESS DRILL DRIVER

Production code..........................................................................

Drilling capacity in steel ..............................................................

Drilling capacity in wood .............................................................

Wood screws (without pre-drilling) .............................................

No-load speed 1st gear ..............................................................

No-load speed 2nd gear .............................................................

Torque ........................................................................................

Battery voltage............................................................................

Drill chuck range .........................................................................

Weight according EPTA-Procedure 01/2003 ..............................

Noise/vibration information

Measured values determined according to EN 60 745.

Typically, the A-weighted noise levels of the tool are:

Sound pressure level (Uncertainty K=3dB(A)) ...........................

Sound power level (Uncertainty K=3dB(A)) ................................

Wear ear protectors!

Total vibration values (vector sum in the three axes)

determined according to EN 60745.

Vibration emission value

  Drilling into metal a

h.D

 ..............................................................

  Uncertainty K= ........................................................................

  Screwing a

h

 .............................................................................

  Uncertainty K= ........................................................................

 WARNING! Read all safety warnings and all instructions.

Failure to follow the warnings and instructions may result in electric

shock, fi re and/or serious injury.

Save all warnings and instructions for future reference.

DRILL SAFETY WARNINGS

Use auxiliary handle(s), if supplied with the tool.

 Loss of control

can cause personal injury.

Hold power tool by insulated gripping surfaces, when

performing an operation where the cutting accessory may

contact hidden wiring.

Cutting accessory contacting a „live“ wire may make exposed

metal parts of the power tool „live“ and could give the operator an

electric shock.

SCREWDRIVER SAFETY WARNINGS

Hold power tool by insulated gripping surfaces, when

performing an operation where the fastener may contact

hidden wiring.

Fasteners contacting a "live" wire may make

exposed metal parts of the power tool "live" and could give the

operator an electric shock.

ADDITIONAL SAFETY AND WORKING INSTRUCTIONS

Use protective equipment. Always wear safety glasses when

working with the machine. The use of protective clothing is

recommended, such as dust mask, protective gloves, sturdy

non-slip footwear, helmet and ear defenders.
The dust produced when using this tool may be harmful to health.

Do not inhale the dust. Wear a suitable dust protection mask.

Do not machine any materials that present a danger to health (e.g.

asbestos).
Switch the device off  immediately if the insertion tool stalls! Do not

switch the device on again while the insertion tool is stalled, as

doing so could trigger a sudden recoil with a high reactive force.

Determine why the insertion tool stalled and rectify this, paying

heed to the safety instructions.
The possible causes may be:

•  it is tilted in the workpiece to be machined

•  it has pierced through the material to be machined

•  the power tool is overloaded
Do not reach into the machine while it is running.
The insertion tool may become hot during use.

WARNING!

Danger of burns

•  when changing tools

•  when setting the device down
Chips and splinters must not be removed while the machine is

running.
When working in walls ceiling, or fl oor, take care to avoid electric

cables and gas or waterpipes.
Clamp your workpiece with a clamping device. Unclamped

workpieces can cause severe injury and damage.
Remove the battery pack before starting any work on the machine.
Do not dispose of used battery packs in the household refuse or by

burning them. AEG Distributors off er to retrieve old batteries to

protect our environment.
Do not store the battery pack together with metal objects (short

circuit risk).

WARNING

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 60745

and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for diff erent applications, with

diff erent accessories or poorly maintained, the vibration emission may diff er. This may signifi cantly increase the exposure level over the total

working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off  or when it is running

but not actually doing the job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eff ects of vibration such as: maintain the tool and the accessories, keep

the hands warm, organisation of work patterns.
