BS 12C2

....................... 4478 68 01...

   ...000001-999999

.............................10 mm

.............................20 mm

...............................6 mm

....................... 0-350 min

-1

..................... 0-1500 min

-1

.............................34 Nm

.............................40 Nm

.............................12 V

.............................10 mm (3/8")

............................1,1 kg

............................1,3 kg

..........................67,5 dB (A)

..........................78,5 dB (A)

............................1,6 m/s

2

............................1,5 m/s

2

............................0,9 m/s

2

............................1,5 m/s

2

ENGLISH

TECHNICAL DATA

CORDLESS DRILL DRIVER

Production code............................................................................

Drilling capacity in steel ................................................................

Drilling capacity in wood ...............................................................

Wood screws (without pre-drilling) ...............................................

No-load speed, 1st gear ...............................................................

No-load speed, 2nd gear ..............................................................

Torque * (1.5 Ah / 2.0 Ah) .............................................................

Torque * (3.0 Ah / 4.0 Ah) .............................................................

Battery voltage..............................................................................

Drill chuck range ...........................................................................

Weight according EPTA-Procedure 01/2003 (1.5 Ah / 2.0 Ah) .....

Weight according EPTA-Procedure 01/2003 (3.0 Ah / 4.0 Ah) .....

Noise/vibration information

Measured values determined according to EN 60 745.

Typically, the A-weighted noise levels of the tool are:

  Sound pressure level (Uncertainty K=3dB(A)) ..........................

  Sound power level (Uncertainty K=3dB(A)) ...............................

Always wear ear protectors!

Total vibration values (vector sum in the three axes) determined

according to EN 60745.

Vibration emission value ah

  Drilling into metal .......................................................................

  Uncertainty K .............................................................................

  Screwing ....................................................................................

  Uncertainty K .............................................................................

* Measured according to AEG standard N 877318

 WARNING! Read all safety warnings and all

instructions.

Failure to follow the warnings and instructions

may result in electric shock, fi re and/or serious injury.

Save all warnings and instructions for future reference.

DRILL SAFETY WARNINGS

Hold power tool by insulated gripping surfaces, when

performing an operation where the cutting accessory may

contact hidden wiring.

Cutting accessory contacting a „live“ wire may make exposed

metal parts of the power tool „live“ and could give the operator

an electric shock.

SCREWDRIVER SAFETY WARNINGS

Hold power tool by insulated gripping surfaces, when

performing an operation where the fastener may contact

hidden wiring.

Fasteners contacting a "live" wire may make

exposed metal parts of the power tool "live" and could give the

operator an electric shock.

ADDITIONAL SAFETY AND WORKING INSTRUCTIONS

Use protective equipment. Always wear safety glasses when

working with the machine. The use of protective clothing is

recommended, such as dust mask, protective gloves, sturdy

non-slip footwear, helmet and ear defenders.
The dust produced when using this tool may be harmful to

health. Do not inhale the dust. Wear a suitable dust protection

mask.
Do not machine any materials that present a danger to health

(e.g. asbestos).

Switch the device off immediately if the insertion tool stalls! Do

not switch the device on again while the insertion tool is stalled,

as doing so could trigger a sudden recoil with a high reactive

force. Determine why the insertion tool stalled and rectify this,

paying heed to the safety instructions.
The possible causes may be:

•  it is tilted in the workpiece to be machined

•  it has pierced through the material to be machined

•  the power tool is overloaded
Do not reach into the machine while it is running.
The insertion tool may become hot during use.

WARNING!

Danger of burns

•  when changing tools

•  when setting the device down
Chips and splinters must not be removed while the machine is

running.
When working in walls ceiling, or fl oor, take care to avoid

electric cables and gas or waterpipes.
Clamp your workpiece with a clamping device. Unclamped

workpieces can cause severe injury and damage.
Remove the battery pack before starting any work on the

machine.
Do not dispose of used battery packs in the household refuse

or by burning them. AEG Distributors offer to retrieve old

batteries to protect our environment.
Do not store the battery pack together with metal objects (short

circuit risk).
Use only System PCLS chargers for charging System PCLS

battery packs. Do not use battery packs from other systems.

WARNING

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN

60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained, the vibration emission may differ. This may signifi cantly increase the

exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or when it is

running but not actually doing the job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the

accessories, keep the hands warm, organisation of work patterns.

ENGLISH

Never break open battery packs and chargers and store only in

dry rooms. Keep dry at all times.
Battery acid may leak from damaged batteries under extreme

load or extreme temperatures. In case of contact with battery

acid wash it off immediately with soap and water. In case of eye

contact rinse thoroughly for at least 10 minutes and

immediately seek medical attention.

SPECIFIED CONDITIONS OF USE

The battery drill/screwdriver may be used for drilling and

screwdriving for independent use away from mains supply.
Do not use this product in any other way as stated for normal

use.

EC-DECLARATION OF CONFORMITY

We declare under our sole responsibility that the product

described under “Technical Data” fulfi lls all the relevant

provisions of the directives 2011/65/EU (RoHs), 2004/108/EC,

2006/42/EC and the following harmonized standards have

been used:
EN 60745-1:2009 + A11:2010

EN 60745-2-1:2010

EN 60745-2-2:2010

EN 55014-1:2006 + A1:2009 + A2:2011

EN 55014-2:1997 + A1:2001 + A2:2008

EN 50581:2012

Winnenden, 2015-03-02

Alexander Krug

Managing Director
Authorized to compile the technical fi le
Techtronic Industries GmbH

Max-Eyth-Straße 10

71364 Winnenden

Germany

BATTERIES

Battery packs which have not been used for some time should

be recharged before use.
Temperatures in excess of 50°C (122°F) reduce the

performance of the battery pack. Avoid extended exposure to

heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully

charged, after used.
To obtain the longest possible battery life remove the battery

pack from the charger once it is fully charged.
For battery pack storage longer than 30 days:

Store the battery pack where the temperature is below 27°C

and away from moisture

Store the battery packs in a 30% - 50% charged condition

Every six months of storage, charge the pack as normal.

BATTERY PACK PROTECTION

The battery pack has overload protection that protects it from

being overloaded and helps to ensure long life.

Under extreme stress the battery electronics switch off the

machine automatically. To restart, switch the machine off and

then on again. If the machine does not start up again, the

battery pack may have discharged completely. In this case it

must be recharged in the battery charger.

TRANSPORTING LITHIUM BATTERIES

Lithium-ion batteries are subject to the Dangerous Goods

Legislation requirements.
Transportation of those batteries has to be done in accordance

with local, national and international provisions and regulations.

•  The user can transport the batteries by road without further

requirements.

•  Commercial transport of Lithium-Ion batteries by third parties

is subject to Dangerous Goods regulations. Transport

preparation and transport are exclusively to be carried out by

appropriately trained persons and the process has to be

accompanied by corresponding experts.

When transporting batteries:
•  Ensure that battery contact terminals are protected and

insulated to prevent short circuit.

•  Ensure that battery pack is secured against movement within

packaging.

•  Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice

MAINTENANCE

Use only AEG accessories and spare parts. Should

components need to be replaced which have not been

described, please contact one of our AEG service agents (see

our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please

state the machine type printed as well as the six-digit No. on

the label and order the drawing at your local service agents or

directly at: Techtronic Industries GmbH, Max-Eyth-Straße 10,

71364 Winnenden, Germany.

SYMBOLS

CAUTION! WARNING! DANGER!

Remove the battery pack before starting any

work on the machine.

Please read the instructions carefully before

starting the machine.

Do not dispose of electric tools together with

household waste material.

Electric tools and electronic equipment that

have reached the end of their life must be

collected separately and returned to an

environmentally compatible recycling facility.

Check with your local authority or retailer for

recycling advice and collection point.

European Conformity Mark

EurAsian Conformity Mark.
