2

| English

 WARNING

Injuries may be caused or aggravated by prolonged use
of a tool. When using any tool for prolonged periods,
ensure you take regular breaks.

KNOW YOUR PRODUCT

See page 93.

1. On/off switch
2.  Variable speed control selector
3.  1/3 Sheet pad
4. Paper Clamp
5.  Dust collection box
6.  Handle, insulated gripping surface
7. Adhesive sandpaper
8. Non-adhesive sandpaper

SANDPAPER SELECTION

Selecting the correct size, grit and type of sand paper is an
extremely important step in achieving a high quality sanded

fi

 nish. Aluminum oxide, silicon carbide, and other synthetic

abrasives are best for power sanding. Natural abrasives,
such as

fl

 int and garnet are too soft for economical use in

power sanding.
In general, coarse grit will remove the most material
and

fi

 ner grit will produce the best

fi

 nish in all sanding

operations. The condition of the surface to be sanded will
determine which grit will do the job. If the surface is rough,
start with a coarse grit and sand until the surface is uniform.
Medium grit may then be used to remove scratches left
by the coarser grit and

fi

 ner grit used for

fi

 nishing of the

surface. Always continue sanding with each grit until
surface is uniform.

 WARNING

Do not use sander without sandpaper; doing so will
damage the cushion.

Sheet/pad recommended use

80-grit sanding sheet

Coarse sanding

120-grit sanding sheet

Light sanding

150-grit sanding sheet

Light sanding

MAINTENANCE

 WARNING

The product should never be connected to a power
supply when assembling parts, making adjustments,
cleaning, performing maintenance, or when the product
is not in use. Disconnecting the product from the power
supply will prevent accidental starting that could cause
serious injury.

■

When servicing, use only identical RYOBI replacement
parts. Use of any other parts may create a hazard or
cause product damage.

■

Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to various types of commercial
solvents and may be damaged by their use. Use clean
cloths to remove dirt, carbon dust, etc.

■

Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. They contain chemicals that can
damage, weaken or destroy plastic.

■

Always wear safety goggles or safety glasses with side
shields during power tool operation or when blowing
dust. If operation is dusty, also wear a dust mask.

■

If the power supply cord is damaged, it must be
replaced only by the manufacturer or by an authorized
service center to avoid risk. Contact authorized service
center.

■

For greater safety and reliability, all repairs should be
performed by an Authorised RYOBI Service Centre.

 WARNING

Electrical tools used on

fi

 berglass material, wallboard,

spackling compounds, or plaster are subject to
accelerated wear and possible premature failure
because the

fi

 berglass chips and grindings are highly

abrasive to bearings, brushes, commutators, etc. We do
not recommend using the product for extended work on
these types of materials.

 WARNING

Do not use compressed air to blow dust from the product.
This practice is dangerous and can cause dirt and grit to
be blasted into someone’s eyes, causing injury.

LUBRICATION

All of the bearings in the product are lubricated with a
suf

fi

 cient amount of high grade lubricant for the life span of

the product under normal operating conditions. Therefore,
no further lubrication is required.

CLEANING THE SANDING SHEETS

The sanding sheets that come with the product are made to
be re-used. Therefore, it is important that they be cleaned
periodically to remove sanding residue and foreign material
that can accumulate over time.
To clean sanding sheets, rub the sheets with a hard rubber
block. You can also use the clean rubber sole of a shoe.

ENVIRONMENTAL PROTECTION

Recycle raw materials instead of disposing
of as waste. The machine, accessories and
packaging should be sorted for environment-
friendly recycling.

SYMBOL

Safety Alert
