ENGLISH

en

8

Keep children away from the

battery charger and the working

area!

Keep your battery charger out of

reach of children!

Pull out the mains plug immediately

if the battery charger starts to

smoke or flames emerge!

Do not insert objects into the

ventilation slots on the battery

charger – there is a danger of

electric shocks and short circuits!

Do not use faulty battery packs.

In areas with high metal dust

exposure do not load any battery

packs with AIR COOLED chargers

(ASC 15, ASC 30-36, ASC ultra).

See page 2.

1 Battery pack (not in scope of delivery)

2 Sliding  seat

3 Operation  display

4 Warning  display

Before plugging in, check to see that the

rated mains voltage and mains frequency, as

specified on the rating label, match your

power supply.

Devices such as this one, which generate direct

current, may have an effect on basic residual-

current circuit breakers. Use type F or better, with a

release current of max. 30 mA.

Before commissioning the charger, ensure that

the air slots are free. Minimum distance to other

objects is 5 cm.

6.1 Self-test

Insert mains supply plug.
The warning display (4) and the operating indicator

(3) light up one after the other for approx. 1 second

and the installed fan runs for approx. 5 seconds.

7.1 Charging battery pack

Push the battery pack

completely to the stop

 on

the sliding seat (2).

The operating indicator (3) flashes.
Note: To have the charge level displayed on Li-ion

battery packs (with 14.4 V, 18 V and 36 V), first take

the battery pack out of the charger and then press

the button on the battery pack.

7.2 Conservation charge

Once the charging process has finished, the battery

charger automatically switches to conservation

mode.
The battery pack can remain in the battery charger

and is therefore always ready for use.

The operating display (3) lights up continuously.

8.1 Warning display (4) lights up

continuously

Battery pack is not charged. Temperature too high/

too low. When the temperature of the battery pack

is between 0 °C and 50 °C, the charging process

begins automatically.

8.2 Warning display (4) flashes

• Battery pack is defective. Remove the battery

pack immediately from the charger.

• The battery pack was not pushed correctly onto

the sliding seat (2). See section 7.1.

Repairs to the charger must only be carried out by

qualified electricians.
If the mains connection cable of this tool is

damaged, in order to prevent endangering

personnel and property it must be replaced by the

manufacturer, or the Customer Service of the

manufacturer, or a similarly qualified person.
Contact your local Metabo representative if you

have Metabo chargers requiring repairs. For

addresses see www.metabo.com.

Observe national regulations on environmentally

compatible disposal and on the recycling of disused

machines, packaging and accessories.

Only for EU countries: Never dispose of

power tools in your household waste! In

accordance with European Guideline

5. Overview

6. Commissioning

7. Use

8. Fault

9. Repairs

10. Environmental Protection
