ENGLISH

en

9

Before plugging in, check that the rated mains

voltage and mains frequency, as stated on the

type plate match your power supply.

The machine must only be connected to a

socket that has been properly earthed in

accordance with regulations.

Always install an RCD with a maximum trip

current of 30 mA upstream.

If an extension cord is needed, it must be a three-

core lead with a protective (earth) contactor that is

properly connected to both the plug and the coupler

of the cord.

6.1 Installation of sanding disc

Simple attachment and removal thanks to the hook

and loop-type fastening. Simply press on the

sanding disc so that the holes in the sanding disc

(11) are aligned with the support plate (10).

6.2 Connect dust extraction

To optimise the dust extraction performance, fit the

sanding disc (11) so that the holes on the sanding

disc are aligned to the support plate (10).
Connect a suitable extraction device to the extractor

connection piece (9).

6.3 Connect the mains cable at the device

Connection:

 Insert mains cable (7) until the stop.

The mains cable lock engages.

Removal:

 Press mains cable lock (8) and remove

mains cable (7).
Connect the mains cable to an earthed socket.

7.1 On/Off switch, setting the speed

Switch on the machine by pressing the On / Off key

(4). The electronic signal indicator (3) now lights up

green.
The machine can now be put into operation by

pressing down the lever (1) .
The machine has 2 operating modes to set the

speed. To change between the operating modes,

press key (5) and key (6) simultaneously.
Operating mode 1:

The speed can be controlled in a linear manner by

changing the lever position (1) .
Operating mode 2:

By pressing the keys (5) or (6) the max. speed

increases / reduces by 1000 min

-1

(rpm). This can

also be done during operation.
The best way to determine the ideal setting is

through a practical trial.
Switch off the machine after the grinding process,

by pressing the On / Off key (4).

7.2 Working Directions

Bring the support plate (10) in contact with the

workpiece and only then switch on the machine.
To end the grinding process, lift the support plate

(10) off the workpiece and only then switch off the

machine.
This prevents the formation of grooves in the

surface due to excessive speeds of the grinding

media.

Pull the plug out of the socket before making

any adjustments, changing tools, carrying out

maintenance or cleaning.

Regularly check

 the device, the support plate, the

mains cable and the connections for wear.

The clean the machine regularly, frequently

and thoroughly.

 This includes vacuum cleaning

the ventilation louvres on the motor.

Clean the support plate as required

 (vacuum off

the dust). This increases the service life of the hook

and loop-type fastening.

Replacing a worn support plate

1. Put the open-end wrench (12) between support

plate (10) and braking ring (13) and thus lock the

spindle.

2. Turn the support plate (10) anti-clockwise (seen

from below) to remove it.

3. Mount the new support plate (order no.:

6.30259000) always with the supplied, pre-

mounted washers.

4. Remove the open-end wrench (12).

Replacing a support plate brake / braking ring

If the idle speed of the support plate increases in

course of time, the braking ring (13) is worn and

must be replaced.
Note: If abrasive material (e.g. gypsum, etc.) is

being sanded, the braking ring inevitably wears

faster.
Note: An excessive suction output of your extraction

device may lead to a malfunction of the support

plate brake.
1. Remove the support plate (10), as shown above.

2. Remove the old braking ring (13) from its groove

and replace with a new braking ring (order no.:

344113630).

3. Reattach the support plate (10) as described

above.

• The electronic signal indicator (3) flashes

red and green alternately:

The machine is connected to a socket with incorrect

voltage.
Before commissioning, check that the rated mains

voltage, as stated on the type plate match your

power supply.

6. Initial Operation

7. Use

8. Cleaning, maintenance

9. Troubleshooting
