13 ENGLISH

Shaft lock

Press the shaft lock to prevent spindle rotation when

installing or removing accessories.

►

Fig.3:

1.

 Shaft lock

NOTICE:

Never actuate the shaft lock when the

spindle is moving.

 The tool may be damaged.

Switch action

CAUTION:

Before installing the battery car-

tridge into the tool, always check to see that the

switch lever actuates properly and returns to the

"OFF" position when released.

CAUTION:

For your safety, this tool is

equipped with lock-off lever which prevents the

tool from unintended starting. NEVER use the tool

if it runs when you simply pull the switch lever

without pulling the lock-off lever. Return the tool

to our authorized service center for proper repairs

BEFORE further usage.

CAUTION:

Do not pull the switch lever hard

without pulling the lock-off lever.

 This can cause

switch breakage.

CAUTION:

NEVER tape down or defeat pur-

pose and function of lock-off lever.

►

Fig.4:

1.

 Lock-off lever

2.

 Switch lever

To prevent the switch lever from being accidentally

pulled, a lock-off lever is provided.

To start the tool, pull the lock-off lever toward the opera

-

tor and then pull the switch lever.

To stop the tool, release the switch lever.

Accidental re-start preventive

function

When installing the battery cartridge while pulling the

switch lever, the tool does not start.

To start the tool, first release the switch lever. Then pull

the lock-off lever, and pull the switch lever.

Electronic torque control function

The tool electronically detects situations where the wheel

or accessory may be at risk to be bound. In the situation,

the tool is automatically shut off to prevent further rotation

of the spindle (it does not prevent kickback).

To restart the tool, switch off the tool first, remove the

cause of sudden drop in the rotation speed, and then

turn the tool on.

Soft start feature

Soft start feature reduces starting reaction.

Electric brake

Only for model GA011G / GA012G / GA013G

Electric brake is activated after the tool is switched off.

The brake does not work when the power supply is shut

down, such as the battery is removed accidentally, with

the switch still on.

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before adjusting or checking function on the tool.

Installing side grip (handle)

CAUTION:

Always be sure that the side grip is

installed securely before operation.

Screw the side grip securely on the position of the tool

as shown in the figure.

►

Fig.5

Installing or removing wheel guard

WARNING:

When using a depressed center

wheel, flap disc, flex wheel or wire wheel brush,

the wheel guard must be fitted on the tool so that

the closed side of the guard always points toward

the operator.

WARNING:

Make sure that the wheel guard is

securely locked by the lock lever with one of the

holes on the wheel guard.

WARNING:

When using an abrasive cut-off

/ diamond wheel, be sure to use only the special

wheel guard designed for use with cut-off wheels.

(In some European countries, when using a diamond

wheel, the ordinary guard can be used. Follow the

regulations in your country.)

For depressed center wheel, flap

disc, flex wheel, wire wheel brush

/ abrasive cut-off wheel, diamond

wheel

1.

  While pushing the lock lever, mount the wheel

guard with the protrusions on the wheel guard aligned

with the notches on the bearing box.

►

Fig.6:

1.

 Lock lever

2.

 Notch

3.

 Protrusion

2.

  While pushing the lock lever toward A, push in the

wheel guard by holding down the portions B as shown

in the figure.

►

Fig.7:

1.

 Wheel guard

2.

 Hole

NOTE:

 Push down the wheel guard straight.

Otherwise, you cannot push the wheel guard

completely.

3.

  While keeping the lock lever and wheel guard

position as described in step 2, rotate the wheel guard

toward C, and then, change the angle of the wheel

guard according to the work.

►

Fig.8:

1.

 Wheel guard

2.

 Hole

NOTE:

 Push the wheel guard completely. Otherwise,

you cannot rotate the wheel guard.

To remove wheel guard, follow the installation proce-

dure in reverse.
