12 ENGLISH

Installing or removing wheel guard

(For depressed center wheel, flap

disc, flex wheel, wire wheel brush

/ abrasive cut-off wheel, diamond

wheel)

WARNING:



When using a depressed center

wheel, flap disc, flex wheel or wire wheel brush,

the wheel guard must be fitted on the tool so that

the closed side of the guard always points toward

the operator.

WARNING:



When using an abrasive cut-off

/ diamond wheel, be sure to use only the special

wheel guard designed for use with cut-off wheels.

(In some European countries, when using a diamond

wheel, the ordinary guard can be used. Follow the

regulations in your country.)

For tool with locking screw type

wheel guard

Mount the wheel guard with the protrusions on the

wheel guard band aligned with the notches on the bear

-

ing box. Then rotate the wheel guard to such an angle

that it can protect the operator according to work. Be

sure to tighten the screw securely.

To remove wheel guard, follow the installation proce

-

dure in reverse.

►

Fig.8:



1.

 Wheel guard

2.

 Bearing box

3.

 Screw

For tool with clamp lever type wheel

guard

Loosen the nut, and then pull the lever in the direction

of the arrow.

►

Fig.9:



1.

 Nut

2.

 Lever

Mount the wheel guard with the protrusions on the

wheel guard band aligned with the notches on the bear

-

ing box. Then rotate the wheel guard to such an angle

that it can protect the operator according to work.

►

Fig.10:



1.

 Wheel guard

2.

 Bearing box

►

Fig.11:



1.

 Wheel guard

Close the lever in direction of the arrow. Then tighten

the wheel guard with fastening the nut. Be sure to

tighten the nut securely. The setting angle of the wheel

guard can be adjusted by opening the lever.

►

Fig.12:



1.

 Lever

2.

 Nut

To remove wheel guard, follow the installation proce

-

dure in reverse.

Installing or removing depressed

center wheel or flap disc

Optional accessory

WARNING:



When using a depressed center

wheel or flap disc, the wheel guard must be fitted

on the tool so that the closed side of the guard

always points toward the operator.

CAUTION:



Make sure that the mounting part

of the inner flange fits into the inner diameter of

the depressed center wheel / flap disc perfectly.



Mounting the inner flange on the wrong side may

result in the dangerous vibration.

Mount the inner flange onto the spindle.

Make sure to fit the dented part of the inner flange onto

the straight part at the bottom of the spindle.

Fit the wheel/ disc on the inner flange and screw the

lock nut with its protrusion facing downward (facing

towards the wheel).

►

Fig.13:



1.

 Lock nut

2.

 Depressed center wheel

3.

 Inner flange

4.

 Mounting part

To tighten the lock nut, press the shaft lock firmly so

that the spindle cannot revolve, then use the lock nut

wrench and securely tighten clockwise.

►

Fig.14:



1.

 Lock nut wrench

2.

 Shaft lock

To remove the wheel, follow the installation procedure

in reverse.

Installing or removing flex wheel

Optional accessory

WARNING:



Always use supplied guard when

flex wheel is on tool.

 Wheel can shatter during use

and guard helps to reduce chances of personal injury.

►

Fig.15:



1.

 Lock nut

2.

 Flex wheel

3.

 Back up pad

4.

 Inner flange

Follow instructions for depressed center wheel but also

use back up pad over wheel. See order of assembly on

accessories page in this manual.

Installing or removing abrasive disc

Optional accessory

►

Fig.16:



1.

 Sanding lock nut

2.

 Abrasive disc

3.

 Rubber pad

1.

  Mount the rubber pad onto the spindle.

2.

  Fit the disc on the rubber pad and screw the sand

-

ing lock nut onto the spindle.

3.

  Hold the spindle with the shaft lock, and securely

tighten the sanding lock nut clockwise with the lock nut

wrench.

To remove the disc, follow the installation procedure in

reverse.

NOTE:

 Use sander accessories specified in this man

-

ual. These must be purchased separately.
