16
| English
1 609 92A 0HA | (20.5.14)
Bosch Power Tools
Safety Warnings for Tile Cutters
Use the tile cutter only for cutting the materials listed
under Intended Use.
Marble or granite as well as tiles with
a rough surface structure and natural stone tiles cannot be
cut.
Keep your fingers clear of the movable parts of the tile
cutter.
Danger of fingers being crushed or contused and
considerably injured.
Wear protective gloves when cutting tiles.
Sharp edges
develop on broken tiles and can cause injuries to the oper-
ator.
When transporting the tile cutter, use only the handles,
tighten all loose components (fences, rulers), press
down the locking lever to lock the guide rail, and fix the
transport safety-lock (see figures 15 and 16).
There is a
risk of injury if it falls down.
Product Description and Specifica-
tions
Intended Use
The tile cutter is intended for cutting ceramic tiles.
Product Features
The numbering of the product features refers to the illustra-
tions on the graphics pages.
1
Scoring and breaking lever
2
Breaking stamp
3
Cutting wheel
4
Guide rail
5
Rulers/Fence
6
Supporting surface
7
Carrying handle
8
Base plate
9
Transport safety-lock
10
Locking lever
11
Support extension (PTC 640)
12
Stop for serial cut (PTC 640)
Accessories shown or described are not part of the standard deliv-
ery scope of the product. A complete overview of accessories can
be found in our accessories program.
Technical Data
Practical Advice
Tile cutter
PTC 470
PTC 640
Article number
3 603 M04 ...
... 3..
... 4..
Max. cutting height
mm
12
12
Max. cutting length of rip
cuts
mm
470
640
Mitre/Bevel Angle
Horizontal
°
0 – 45
0 – 45
Weight according to
EPTA-Procedure 01/2003
kg
7,4
9,1
Problem
Cause
Corrective Measure
See
graphic
Tile does not break
cleanly
Too much pressure applied when scoring the
tile (e.g. on “soft” tiles such as wall tiles or
glazed tiles)
Apply less pressure to the scoring and
breaking lever
1
when scoring
There is tile debris under the spring-mounted
supporting surface
6
Remove tile debris
Tile already breaks when
scoring
Too much pressure applied when scoring the
tile (e.g. on “soft” tiles such as wall tiles or
glazed tiles)
Apply less pressure to the scoring and
breaking lever
1
when scoring
Tile does not break along
the cutting line
Not enough pressure applied when scoring the
tile (e.g. on “hard” tiles such as fine stoneware,
floor tiles or frostproof tiles)
Apply more pressure to the scoring and
breaking lever
1
when scoring
Guide rail
4
not locked
Press down the locking lever
10
to lock it
8
Cutting wheel
3
blunt
Replace cutting wheel
3
E
Tile breaks incorrectly
when making a parallel
cut
Breaking stamps
2
not applied at the end of the
tile
Apply breaking stamps
2
right at the end
of the tile
11a
Tile breaks incorrectly
when making a diagonal
cut
Breaking stamps
2
applied at the end of the tile Apply breaking stamps
2
slightly ahead of
the rulers/fence
5
11b
Tile not stable on the
supporting surface
6
Tile is wider than the supporting surface
6
PTC 640:
Fold out the support extensions
11
C
Cutting wheel
3
snags/judders during
scoring
Too much pressure applied when scoring the
tile
Apply less pressure to the scoring and
breaking lever
1
when scoring
OBJ_BUCH-2139-001.book Page 16 Tuesday, May 20, 2014 12:50 PM
