 | English

1 609 929 X88 | (13.12.10)

Bosch Power Tools

Product Features

The numbering of the product features refers to
the illustration of the machine on the graphics
page.

1

Spindle lock button

2

On/Off switch

3

Auxiliary handle (insulated gripping surface)

4

Grinder spindle

5

Protection guard for grinding

6

Locking screw for protection guard

7

Mounting flange with O-ring

8

Grinding disc *

9

Clamping nut

10

Quick-clamping nut

*

11

Carbide grinding head *

12

Protection guard for cutting *

13

Cutting disc *

14

Protection guard for für grinding cup *

15

Grinding cup *

16

Two-pin spanner for clamping nut *

17

Hand guard *

18

Spacer discs *

19

Rubber sanding plate *

20

Sanding sheet *

21

Round nut *

22

Cup brush *

23

Cutting guide with dust extraction protec-
tion guard *

24

Diamond cutting disc *

25

Handle (insulated gripping surface)

* Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.

Noise/Vibration Information

Measured sound values determined according
to EN 60745.
Typically the A-weighted noise levels of the
product are: Sound pressure level 93 dB(A);
Sound power level 104 dB(A). Uncertainty
K = 3 dB.

Wear hearing protection!

Vibration total values (triax vector sum)
determined according to EN 60745:
Surface grinding: Vibration emission value
a

h

= 8.5 m/s

2

, Uncertainty K = 1.5 m/s

2

.

Disk sanding: Vibration emission value
a

h

= 3.5 m/s

2

, Uncertainty K = 1.5 m/s

2

.

The vibration emission level given in this infor-
mation sheet has been measured in accordance
with a standardised test given in EN 60745 and
may be used to compare one tool with another.
It may be used for a preliminary assessment of
exposure.
The declared vibration emission level repre-
sents the main applications of the tool. However
if the tool is used for different applications, with
different accessories or poorly maintained, the
vibration emission may differ. This may signifi-
cantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibra-
tion should also take into account the times
when the tool is switched off or when it is run-
ning but not actually doing the job. This may sig-
nificantly reduce the exposure level over the to-
tal working period.
Identify additional safety measures to protect
the operator from the effects of vibration such
as: maintain the tool and the accessories, keep
the hands warm, organisation of work patterns.
