Hold the power tool firmly with both hands and make
sure you have a stable footing.

 The power tool can be

more securely guided with both hands.

u

Always wait until the power tool has come to a com-
plete stop before placing it down.

u

Secure the workpiece.

 A workpiece clamped with

clamping devices or in a vice is held more secure than by
hand.

u

In case of damage and improper use of the battery, va-
pours may be emitted.

Ensure the area is well-ventilated

and seek medical attention should you experience any ad-
verse effects. The vapours may irritate the respiratory
system.

u

Do not open the battery.

There is a risk of short-circuit-

ing.

u

The battery can be damaged by pointed objects such
as nails or screwdrivers or by force applied externally.

An internal short circuit may occur, causing the battery to
burn, smoke, explode or overheat.

u

Only use the battery with products from the manufac-
turer.

 This is the only way in which you can protect the

battery against dangerous overload.

Protect the battery against heat, e.g.
against continuous intense sunlight, fire,
water, and moisture.

 There is a risk of explo-

sion.

Product description and
specifications

Read all the safety and general instructions.

Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.

Please observe the illustrations at the beginning of this oper-
ating manual.

Intended Use

The power tool is intended for dry sanding of wood, plastic,
metal, filler and varnished surfaces.
Power tools with electronic control are also suitable for pol-
ishing.

Product Features

The numbering of the product features refers to the diagram
of the power tool on the graphics page.

(1)

Orbital stroke rate preselection thumbwheel

(2)

On/off switch

(3)

Battery charge indicator

(4)

Battery

A)

(5)

Complete dust box (Microfilter system)

(6)

Sanding pad

(7)

Auxiliary handle (insulated gripping surface)

(8)

Battery release button

A)

(9)

Handle (insulated gripping surface)

(10)

Sanding sheet

A)

(11)

Sanding sheet alignment aid

A)

(12)

Screws for sanding pad

(13)

Sanding pad holder

(14)

Extraction outlet

(15)

Filter element (Microfilter system)

(16)

Vacuum hose

(17)

Screw for auxiliary handle

(18)

Wing nut

(19)

Dust extraction adapter

A)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical Data

Random orbit sander

AdvancedOrbit 18

Article number

3 603 CD2 0..

Rated voltage

V

18

Orbital stroke rate preselec-
tion

●

No-load speed n

0

rpm

3000 – 12000

No-load orbital stroke rate

rpm

6000 – 24000

Orbit diameter

mm

3.2

Sanding pad diameter

mm

125

Weight according to EPTA-
Procedure 01:2014

kg

1.7 (1.3 Ah)–
1.8 (2.5 Ah)

A)

Permitted ambient temperature

– during charging

°C

0 to +45

– during operation

B)

 and

during storage

°C

–20 to +50

Recommended batteries

PBA 18V…W–.

PBA 18V…V–.

Recommended chargers

AL 18.. CV

A) Depends on battery in use
B) Limited performance at temperatures < 0 °C

Noise/Vibration Information

Noise emission values determined according to

EN 62841-2-4

.

Typically, the A-weighted sound pressure level of the power
tool is

77

 dB(A). Uncertainty K = 3 dB. The noise level when

working can exceed 80 dB(A).

Wear hearing protection

Total vibration values a

h

 (triax vector sum) and uncertainty K

determined according to

EN 62841-2-4

:

a

h

 =

4.5

 m/s

2

, K =

1.5

 m/s

2

,

The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure detailed in EN 62841
