14

 | English

Product features

The numbering of the product features refers to the diagram
of the power tool on the graphics page.

(1)

Saw blade

A)

(2)

Adjustable base plate

(3)

Saw blade receptacle

(4)

Locking sleeve for saw blade

(5)

Stroke speed selector switch

(6)

On/off switch

(7)

Battery release button

A)

(8)

Battery

A)

(9)

Handle (insulated gripping surface)

(10)

Button for battery charge indicator

A)

(11)

Battery charge indicator

A)

A)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical data

Reciprocating saw

GSA 18 V-LI

Article number

3 601 F4J 0..

Stroke rate control

●

Rated voltage

V=

18

No-load stroke rate n

0

– First gear

min

−1

0–2400

– Second gear

min

−1

0–2700

Tool holder

SDS

Stroke

mm

28

Max. cutting depth

– In wood

mm

250

– In steel (unalloyed)

mm

20

– Pipe diameter

mm

130

Weight according to
EPTA-Procedure 01:2014

kg

3.2–4.2

A)

Permitted ambient temperature

– During charging

°C

0 to +45

– During operation

B)

 and

during storage

°C

−20 to +50

Recommended batteries

GBA 18V...

ProCORE18V...

Recommended chargers

GAL 18...

GAX 18...

GAL 36...

A) Depends on battery in use
B) Limited performance at temperatures <0 °C

Technical data determined using the battery that comes with the
product.

Noise/vibration information

Noise emission values determined according to

EN 62841-2-11

.

Typically, the A-weighted noise level of the power tool is:
Sound pressure level

85

 dB(A); sound power level

96

 dB(A). Uncertainty K=

5

 dB.

Wear hearing protection

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to

EN 62841-2-11

:

Cutting boards with saw blade

S 644 D

:

a

h,B

=

27.5

 m/s

2

, K=

1.5

 m/s

2

,

Cutting wooden beams with saw blade

S 611 DF

:

a

h,WB

=

27.5

 m/s

2

, K=

1.5

 m/s

2

.

The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure and may be used to com-
pare power tools. They may also be used for a preliminary
estimation of vibration and noise emissions.
The stated vibration level and noise emission value repres-
ent the main applications of the power tool. However, if the
power tool is used for other applications, with different ap-
plication tools or is poorly maintained, the vibration level
and noise emission value may differ. This may significantly
increase the vibration and noise emissions over the total
working period.
To estimate vibration and noise emissions accurately, the
times when the tool is switched off or when it is running but
not actually being used should also be taken into account.
This may significantly reduce vibration and noise emissions
over the total working period.
Implement additional safety measures to protect the oper-
ator from the effects of vibration, such as servicing the
power tool and application tools, keeping their hands warm,
and organising workflows correctly.

Assembly

u

Remove the battery from the power tool before carry-
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage.

 There is risk of injury

from unintentionally pressing the on/off switch.

Battery Charging

u

Use only the chargers listed in the technical data.

 Only

these chargers are matched to the lithium-ion battery of
your power tool.

Note:

The battery is supplied partially charged. To ensure

full battery capacity, fully charge the battery in the charger
before using your power tool for the first time.
The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging process
does not damage the battery.
The lithium-ion battery is protected against deep discharge
by the "Electronic Cell Protection (ECP)". When the battery

1 609 92A 4TG | (05.04.2019)

Bosch Power Tools
