English

4

M o u n t   t h e   m o u n t i n g   b ra c ke t   to   t h e
preferred position in the wall� Push and
slide the device to lock it into place� Then
connect the antennas to the device�

2� Install the waterproof seal� (for certain devices)

Before installing, fit the Ethernet cable through

the spiral cover, bracket, and O-ring� Then follow
the steps as shown in the picture:
(1) Connect the Ethernet cable to the port�
(2) Fit the O-Ring to the head of the bracket, and
screw the bracket to the body of the device�
(3) Fit the Ethernet cable through the seal’s slit
with the thicker side towards the bracket�
(4) Plug the seal to the bracket�
(5) Screw the spiral cover to the bracket�

Spiral Cover

O-Ring

Seal

Bracket

1

2

3

4

5

Software Configurations

■

Managed Mode

To configure mass devices via a centralized management software or a wireless

controller, please refer to the corresponding User Guide� You can download the

User Guide from our website

http://www.tp-link.com

�

■

Standalone Mode

To configure a device through a web-based management system, please follow the

steps below�

1.

Launch a web browser and enter the IP address of your device in the address

bar and press

Enter

�

Note:

•

For EAP, you can check the IP address through your router.

•

For  other  products,  the  default  IP  address  is  192.168.0.254  and  the  IP  address  of  your

computer should be set as 192.168.0.x (“x” is any number from 1 to 253).

2.

Enter

admin

 for both User Name and Password for login�

3.

Change the default User Name and Password to protect your device, then start

configuring the device.
