1

English

Connect the Hardware

According to the diagram in the opening chapter of this guide, follow the steps to connect the hardware.

If  your  internet  connection  is  through  an  Ethernet  cable  from  the  wall  instead  of  through  a  DSL/Cable/Satellite

modem, connect the Ethernet cable directly to the router’s WAN port, and follow Step 3 to complete the hardware

connection.

Step 1

: Turn off the modem, and remove the backup battery if it has one.

Step 2

: Connect the modem to the WAN port on your router with an Ethernet cable.

Step 3

: Turn on the router, and wait for it to start.

Step 4

: Turn on the modem.

Configure the Router

1.

Connect your computer to the router (Wired or Wireless).

•

Wired:

 Turn off the Wi-Fi on your computer and connect your computer to the router’s LAN port using an

Ethernet cable.

•

Wireless:

 Find the product label on the router. Scan the QR code to join the preset 2.4 GHz network directly, or

use the default network names (SSIDs) to join the 2.4 GHz or 5 GHz network.

Note: Only certain models have QR codes.

2.

Launch a web browser and enter

http://mwlogin.net

 in the address bar. Create a password for future logins.

Note: If the login window does not appear, please refer to

FAQ > Q1

.

3.

Follow the step-by-step instructions of

Quick Setup

 to set up your internet connection and wireless network.

Enjoy the internet!

Note: If you have changed the SSID and wireless password during the configuration, use the new SSID and wireless password to join

the wireless network.
