CONNECTION AND OPERATION

Attention! The built-in battery must be charged completely prior to the application.

Speaker system battery charging

•

 Connect the speaker to the 230V mains socket via the jack

r

 using the power cord

(included)  or  via  the  jack

n

  to  the  6V  battery  charger  (not  included).  During  battery

charging the indicator

p

is red.

•

The battery is used in the speaker system as an integral part of the device, therefore

do not try to extract or replace it, because this can result in the warranty cancellation or

the device damage.

•

Adjust the overall volume level by turning the knob

a

.

Attention! For powering the speaker, it is possible to use D/UM-1 batteries (2 pcs.)

(not included). Install them into the battery compartment

s

. Observe the polarity.

17

SRP-555

ENG

User’s Manual

TECHNICAL SPECIFICATIONS

Notes:

• Technical specifications given in this table are supplemental information and cannot

give occasion to claims.

• Technical specifications and package contents are subject to change without notice

due to the improvement of SVEN production.

Technical support is on www.sven.fi.

Parameter, measurement unit

Frequency range, Hz
Output power (RMS), W
Membrane, mm
Power supply, V

Weight, kg
Dimensions, mm

Value

150 – 20 000

3
Ø 76

~

230V / 50Hz, DC6V, battery, battery type

D / UM-1 (1.5V) - 2 pcs.

0.72
172 × 130 × 80
