Notes.  Technical  specifications  given  in  this  table  are  supplemental  information  and

cannot  give  occasion  to  claims.  Technical  specifications  and  package  contents  are

subject to change without notice due to the improvement of SVEN production.

Technical support is on www.sven.fi.

17

SRP-525
SRP-535

ENG

User’s Manual

CONNECTION AND OPERATION

Attention! The built-in battery must be charged completely prior to the application.

Speaker system battery charging

•

 Connect the speaker to the 230V mains socket via the jack

r

 using the power cord

(included) or via the jack

d

 to the 4.5V battery charger (not included). During battery

charging the indicator

c

is red.

•

The battery is used in the speaker system as an integral part of the device, therefore

do not try to extract or replace it, because this can result in the warranty cancellation or

the device damage.

•

Adjust the overall volume level by turning the knob

f

.

Attention! For powering the speaker, it is possible to use D/UM-1 batteries (2 pcs.)

(not included). Install them into the battery compartment

q

. Observe the polarity.

TECHNICAL SPECIFICATIONS

Parameter, measurement unit

Frequency range, Hz

Output power (RMS), W
Speaker diameter, mm
Power supply, V

Weight, kg

Dimensions, mm

           Value                                Value

        SRP-525                        SRP-535

150 – 20,000
3
Ø 76

 ~

230V / 50Hz, DC4.5V, battery,

battery type D / UM-1 (1.5V) - 2 pcs.

0.65

182 × 120 × 80                  180 × 120 × 82
