INSTRUCTIONS FOR USE

Assemble the unit

Note:

 Ensure that the handheld vacuum cleaner is not connected to the charger before assembling the

Metal tube.
1. Take out of handheld vacuum cleaner, metal tube and floor brush.
2. Insert the extended tube into the suction inlet of handheld vacuum cleaner and you will hear the

“click”. When the extended tube is assembled rightly. Please make sure that the extended tube is

inserted rightly before use the upright vacuum cleaner
3. Connect the floor brush with the extended tube. Please insert the extended tube into the floor brush.

You will hear the “click” when the extended tube is assembled rightly.
4. Insert the battery pack in the battery compartment of main body. Assure that is completely fixed.

Triple Handle position

Press the button in indicated on the figure 1 to use the handle on the position 2.
Press the button indicated on the figure 2 to use the handle on the position 3, return to 2 and return to 1.

Use the upright vacuum cleaner

Note:

 Please take out of the charger before use the vacuum cleaner. If the vacuum cleaner is charging

or very low battery status, the vacuum cleaner will not work.
1. To use the upright vacuum cleaner, ensure that the handheld vacuum cleaner is connected with the

extended tube and floor brush rightly.
2. To switch the appliance on, press the ON/OFF button. Both the LED lights on the suction head and

the pilot lights on the main body will light on in blue (3).
3. You can choose the suction power by pressing the speed adjusting button
4. After use, switch off the appliance (1).

Battery status indicator

Note:

 The battery status indicator light will blink when the battery capacity is not enough.

The battery status indicator is with 4 lights to indicate the battery capacity. 4 blue lights: battery

capacity>75%; 3 blue lights: battery capacity 75%~50%; 2 blue light: battery capacity 50%-25%; 1 blue

light< 25%; 1 blue blinking light: battery capacity –empty.

Charging your vacuum cleaner

Note:

 The handheld vacuum cleaner will not work when it’s charging with charger.

1. Place the unit or handheld vacuum cleaner near an electrical power outlet and plug in the charger.
2. Connect the charger to the charging socket. The battery status indicator lamp will dynamically shine to

indicate that the vacuum cleaner is property connected to the charger and that the unit is being charged.

When it’s fully charged, all the 4 lamps will light.

MAINTENANCE AND CLEANING

Caution:

The suction hole opening must be open and free of any obstructions at all times. Otherwise,

the motor will overheat and can be damaged.

Note:

In order for the vacuum to work at top performance all the time, empty the dust container after

each use and clean the dust filter after 5 cleanings.
1. Switch off the appliance and let it cool before undertaking any cleaning task.
2. Clean the outside of the appliance with a damp cloth. Do no use abrasive products or solvents.
3. Do not submerge the appliance in water or any other liquid. Make sure no water enters the appliance.
4. Remove any dirt (hair and other fibers) tangled around the brush and wheels.
