Congratulations on your new
purchase!
Enjoy your appliance to the full through
correct usage.

Applications

You are now the owner of one of the most efficient
and versatile appliances available, which can easily be
adapted for any one of its four cleaning functions. The
THOMAS SUPER 30 S Aquafilter can be used as a
vacuum cleaner for cleaning carpets, upholstery,
smooth floors and for regular household care; it can
vacuum dirt as well as liquids, e.g. it can clear blocked
sinks and drains. With only a few simple accessories, it
can be used for shampooing your carpets or
upholstery.
The THOMAS SUPER 30 S Aquafilter is a multi-purpose
product. In conjunction with the cleaning solution, the
spray-extraction function enables you to clean carpets,
upholstery and hard floors. The window-cleaning
nozzle also renders it suitable for cleaning windows.
The wet vacuuming mode is suitable for picking up
water-based liquids only and it should never be used
for vacuuming inflammable liquids. As a vacuum
cleaner, it is intended for the removal of dry dirt and
dust from  carpets, floors, furniture and curtains.

Unpacking the appliance

Unpack the appliance from the carton, remove any
packaging and identify the following parts and
functions in the diagrams at the beginning of this
booklet to gain a better understanding of the
instructions given below.
The letters indicated below refer to the diagrams on
pages 4 and 6.

Assembly instructions

The parts required for the chassis are to be found
loosely packed in the carton.

Assembling the castor wheels

A Undo the snap-on fasteners (3) and lift off the

motor block (2).

B

Take out the extraction liquid tank (28) and
cleaning solution. Turn the collecting bin (1) upside
down, i.e. with the opening facing the floor.

C To facilitate assembly, we recommend lightly

greasing the pegs at both ends.
First insert the pegs (30) in the base of the
collecting bin (1), then push them in, together with
the castors (4), as far as they will go.
Turn the collecting bin (1) back over onto the
castors (4) and check that these have been
correctly assembled by moving the collecting bin
(1) back and forth in all directions.

Fitting the motor block

D Place the motor block (2) on the collecting bin (1),

making sure that the surfaces of both parts
correspond. Secure the motor block (2) by means
of both snap-on fasteners (3).

Connecting the flexible hose

E

Insert the flexible hose (13) in the suction socket
(8) in such a manner that the markings on both
the suction socket and the hose connecting piece
correspond and the button clicks into place. Then
attach the desired accessories.
Remove the hose by turning the hose connecting
piece and slowly with drawing the hose.

Suction tube holder

F

The suction tubes (14) complete with accessories
and flexible hose (13) can be hooked into the
fixtures at the back of the appliance.

Cable storage

G After use, the mains cable (10) can be wound

loosely in the hand and hung over the notch in
the carrying handle, as shown in the illustration.

Motor protection filter

J

After each wet suction and spray extraction
process, check the motor protection filter (33) for
contaminations and clean if required. For this,
open the float valve (38) in the direction of the
arrow, and take the motor protection filter from
the suction opening.
Replace the cleaned or new filter and then put
the float valve back in place.

Concentrated cleaning solution

Your THOMAS SUPER 30 S Aquafilter contains 0.5 l of
Protex cleaning concentrate. Please see bottle label
for instructions for use and dosage.
