Cleaning and care of the AQUA filter

system

For reasons of hygiene, empty, clean

and dry the AQUAFILTER system the

waterfiltercartridge and the collecting

bin after each use.  Dirty water and

damp parts will promote the growth of

bacteria and mildew.

Clean the waterfiltercartridge – according to how dirty

it is – with clear water, without adding any detergents

or cleaning fluids.  Please make sure that the filter is

completely dry before next using the vacuum cleaner.

 Wet vacuuming

Keep the float valve (40, fig. P) clean and

accessible at all times. It automatically interrupts

vacuuming when the collecting bin is full.

When vacuuming out containers in which the liquid

level is higher than the top of the collecting bin and

which have a larger volume than the capacity of the

collecting bin, liquid can continue to be vacuumed

beyond the capacity of the collecting bin if the float

valve is closed.
In such cases, vacuum only in partial amounts and

intermittently empty the collecting bin.
Lift the tube and flexible hose out of the liquid first

and then turn off the appliance afterwards, in order to

prevent an afterflow of liquid.

A

  Open the snap-on fasteners and lift the motor

block.

Remove the filters from the appliance, because

they will otherwise be damaged

(figures C and D).

If the cleaning fluid tank is fitted, remove it

(figure H).

F

  Place the motor block onto the collecting bin and

snap shut with snap-on fasteners.

Connect the mains cable.

G

  Connect flexible hose. Remove the hose by

turning the hose connecting piece to the side and

withdrawing the hose.

M

  Close the suction power control (11) on the

handle.

K

  Switch on the appliance with the On/Off (6)

switch.

The pump switch (7) must not light up.

After completion of wet vacuuming, please clean

and dry the appliance and the accessories used.

 Spray extraction (shampooing) of

 carpets and hard floor coverings

Shampoo only carpets which can be cleaned wet.

Fine, hand-woven or non-colour-fast carpets

should not be shampooed.

If the carpet has been shampooed before, it is

possible that you will obtain a great deal of foam

when you use THOMAS PRESTIGE for the first

time.

If this is the case, switch off the appliance and

empty the collecting bin.

Thereafter, in order to prevent excess foam, put

1

⁄

2

 cup of vinegar into the collecting bin.

Excess foaming will not occur after you have

thoroughly cleaned the carpet once with

THOMAS cleaning concentrate, because it

contains a special anti-foam substance.

Ensure that there is always liquid in

the fresh water container when the

spraying function is switched on, in

order to avoid possible damage to the

pump.

Carpet cleaning

A

  Open the snap-on fasteners and lift the motor

block.

H

  Remove the lid of the cleaning fluid tank and fill

the tank with THOMAS ProTex Cleaning Fluid.

See the bottle label for dosage instructions.

Use only lukewarm (max. 30 °C) water.

Replace the lid and insert the filled cleaning fluid

tank into the appliance.

E

  Take the suction hose for cleaning fluid out of its

holder on the motor block.

I

  Place the motor block onto the collecting bin such

that the suction hose (36) is immersed all the way

to the bottom of the cleaning fluid tank and is not

bent.

G

  Connect flexible hose. Remove the hose by

turning the hose connecting piece to the side and

withdrawing the hose.

J

  Insert the cut-off valve into its receptacle on the

suction tube.  Snap the handle into the suction

tube and fasten the cleaning fluid hose to the

flexible hose by means of the plastic clips.

K

  Snap the cleaning fluid hose into the quick

coupling on the motor block.

L

  Fit the carpet spray extraction nozzle onto the

suction tube.

13
