17

 General instructions

To connect up suction hose

–  Insert the suction hose connection piece in the appliance connector

and turn backwards until it locks.

–  Push spray hose in the fast coupling until it engages.

To remove suction hose

–  Press the button on the connection piece. Turn the connection piece

one quarter of a turn to the side and draw out.

–  To release spray hose: press the fast coupling button.

Electronic suction power control

Switch the appliance on/off by gently pressing the power ON/OFF
key.
1.  Press down the key briefly:

Appliance switches on; rating 850 Watt (ECO stage); green indi-
cator lamp comes on

2. Hold-down key:

Infinitely variable electronic suction power control
between 650 and 1600 Watt

Signal lamp green: MIN. 650 Watt to 1125 Watt;
Signal lamp yellow: 1125 Watt to MAX. 1600 Watt.
The signal lamp goes out briefly if the appliance is running at minimum
or maximum capacity.
3.  Press key briefly again:

Appliance turns off.

  The AQUAFILTER system offers particularly good filtration at

a rating between 850 W (ECO stage) and MAX 1600 W.

Consequently only use the appliance at MIN rating (650 Watt)
for a short time (when vacuuming curtains, for example).

Mechanical suction power control

The suction power can also be adjusted by means of the mechanical
suction power controller (auxiliary air slide).

Auxiliary air slide closed = full suction power
Auxiliary air slide open = reduced suction power.

  The auxiliary air slide must always be closed in case of using the

electronic suction power control system and during sucking up.

Mechanical spraying quanti-
ty regulating

Note: Only to be used during wash

cleaning.

You can mechanically vary the
spraying volume from 250 ml (min)
to 800 ml (max) infinitely by means
of the setting wheel on the handle of
the suction hose.

Parking position

–  Hang the complete suction tube with nozzle and hose in the suction

tube holder on the back of the appliance.

  Hang the suction tube on the bottom of the appliance should the

appliance be stored in the upright position (only possible if appli-
ance is empty).

Accessory storage

•

The fresh water tank can be used to store accessories during using
the cleaner for dry cleaning

 Dust vacuuming with AUQA-Filter

Information for use

•

Do not use the TWIN HYGIENE PLUS T2 for dry
vacuuming if the AQUAFILTER system has not been
appropriately fitted according to the operating inst-
ructions. This could cause damage to the appliance.

•  Do not suck up any liquids during dry vacuuming.

•

Do not suck up any large quantity of fine dust, for
example, chocolate powder, flour, etc.

To make the AQUA filter ready for use

THOMAS has set your TWIN HYGIENE PLUS T2 ready for dry
vacuuming.

Open appliance cover by lifting up the cover catch.

Draw out the AQUA filter from the waste water tank by means
of the grip. Fill up the waste water tank with 1 litre clean water.

Insert the complete AQUA filter up to the stop behind the two
guide ribs of the waste water tank. At the same time make sure
that the wet filter is fitted and the circumventing AQUA filter
seal is tight up against the inside of the waste water tank.

Connect up suction hose and fit telescopic suction tube. Connect the
required accessory.

To achieve optimal filtration we recommend rinsing out the
AQUA filter quickly with clear water after approx. 40-60
minutes continuous operation or if a large number of drops of
water can be seen on the underside of the cover. You should
also change the water in the waste water tank.

In case of larger volumes of dust (for example when cleaning
intensively or for the first time) the Aquafilter may possibly
have to be flushed out and the water changed earlier.

For hygienic reasons the AQUAFILTER system is to be
emptied and cleaned every time the appliance is used.
Waste water and moist parts propagate the growth
of bacteria and fungi (see cleaning and maintenance
instructions).

 Dust vacuuming with Hygiene-Box

Information for use

•

Do not use the TWIN HYGIENE PLUS T2 for dry vacu-
uming if the hygiene box has not been appropriate-
ly fitted according to the operating instructions. This
could cause damage to the appliance.

•  Do not suck up liquids when dry vacuuming.

•

Do not suck up any large quantity of fine dust, for
example, chocolate powder, flour, etc.

Getting the appliance going:

Take out the waste water tank and insert the hygiene box incl. HEPA
bag.
Connect up suction hose (27) and fit telescopic suction tube. Connect
the required accessory.

800 ml

max.

250 ml

min.
