4

SUCTION  POWER CONTROL (REMOTE CONTROL MODEL  ONLY)

Your cleaner has variable electronic suction control to give you greater  versatility.
Select the most suitable position according to cleaning needs.
The suction capacity can be regulated steplessly by moving the slide to the desired position.

SLIDE THE PART “A” IN THE STOP POSITION
Vacuum cleaner switches off (stand by mode)

SLIDE THE PART “A” TOWARDS MAX
Suction capacity increases steplessly up to MAX.

A

DUST INDICATOR

You may continue cleaning until the dust indicator changes  and displays red colour. This means the
dust bag is full and needs to be replaced.
If the indicator suddenly displays red and the cleaner loses suction power while in use, turn your cleaner
off and check whether the hose, pipe or nozzle is clogged.
When you check bag status by indicator, set motor power on maximum position.

DUST BAG REMOVAL(DUST COVER)

NOTE :

Hose must be disconnected before changing bag.
Replace the dust bag as soon as it is full.

1. To open the dust cover of the dust bag compartment, lift the cover

upward.

2. Remove the dust bag from the cleaner.

3. Dispose of the full bag. Insert the cardboard bag collar of the dust

bag as far as it can go on the suction inlet along the slide guide.
Position the dust bag so that no part of the bag is pinched.

4. Press the front of dust cover down lightly  until it re-locks.
