PC-AKS3034_IM_new
26.08.19
32
Overview of the Components /
Scope of Delivery
1 Dust container release button
2 Charging indicator lamp
3 On / off switch
4 Handle
5 Socket for mains adapter
6 2-part filter insert
7 Dirt collection container
8 Connector for accessories
9 Attachment for wet vacuuming
10 Crevice nozzle, short
11 Wall mount
12 Power adapter
13 Crevice nozzle, long
Not Shown
Brush attachment
Notes for Use
• The appliance is especially suitable for quickly vacuum-
ing small amounts of dry dirt or dust.
• It is furthermore suitable for vacuuming a limited amount
of wet dirt or liquids.
• Contaminated filters reduce the suction power of the
vacuum cleaner, which is why we recommend regular
cleaning of the dirt filters existing.
• The appliance is operated via charged battery. Charge
the battery using the power adapter provided. Direct
power supply via mains adapter is not possible.
On / Off Switch
I
= Appliance on
O
= Appliance off
Nozzle Attachments
The different nozzle attachments are easy to attach and to
remove.
Assembly the Wall Holder
Inserting the Plug of the Power Supply Unit
If you want to use the wall holder also as the charging
station, attach the plug of the power supply unit first. Refer
to the illustrations (A and B) on page 3.
NOTE:
Turn the plug at the metal end,
not
at the cable. Use a
pliers if necessary.
1. Set the plug of the power supply unit with the flattened
side into the wall holder. (Fig. A)
2. Turn the plug of the power supply unit by 90 °. It must
sit solidly in the holder and sliding no longer shall be
possible. (Fig. B)
3. Fix the cable in the cable guide.
Fastening the Wall Holder
WARNING:
Make sure beforehand whether there are cables in the
wall which could be damaged!
CAUTION:
Place the wall holder so that the appliance is not exposed
to direct sunlight or other heat sources.
NOTE:
A power outlet must be near.
1. Hold the wall mount against the wall with the drill holes at
the bottom of the mount. Mark 2 drill holes.
2. Drill the holes and insert the wall plugs into the wall.
3. Insert the screws through the holes of the wall holder.
4. Tighten the screws with a screwdriver hand-tight.
Charging the Battery
CAUTION:
Do
not
charge the rechargeable battery unsupervised.
1. Turn off the appliance (switch position:
O
).
2. Connect the power supply unit with the connection
socket (5). If you have prepared the wall holder as a
charging station, suspend the appliance from the wall
holder.
3. Connect the mains adapter to a certified wall socket.
Charge the appliance for 4,5 hours before first-time use.
NOTE:
• The indicator lamp lights up red during charging.
• Once the battery is fully charged, the indicator lamp
lights up green.
• It is normal for the appliance to heat up during
charging.
4. Stop all other charging process after a maximum of
4.5 hours or once the indicator light stays permanently
on.
CAUTION:
Always remove the mains plug from the power outlet after
charging is complete.
NOTE:
Even when switched off, the rechargeable battery dis-
charges continuously. If the appliance is out of use for a
longer period of time, charge the rechargeable battery at
least once every 4 to 6 weeks.
Using the Appliance
• Disconnect the appliance from the mains adapter.
• Use the switch to switch the appliance on (
I
) or off (
O
).
