4

Lift the dustbag holder out of the appliance (fig. 24).

Make sure you hold the dustbag upright when lifting it out of the appliance.

5

Remove the full dustbag from the holder by pulling the cardboard tag (fig. 25).

When you do this, the dustbag will be automatically sealed.

6

Slide the cardboard tag of the new dustbag into the two grooves of the dustbag holder as far
as possible. Re-insert the dustbag holder into the vacuum cleaner (fig. 26).

You cannot close the cover if no dustbag has been inserted.

◗

If provided, you can use the cotton dustbag instead of paper dustbags. The cotton dustbag can
be used and emptied repeatedly.

To empty the cotton dustbag:
-

Hold the dustbag over a dustbin.

-

Remove the clip by sliding it off the dustbag sideways.

-

Close the dustbag by sliding the clip back onto the bottom edge of the dustbag.

Filters

Motor Protection Filter

Ever y time you empty or replace the dustbag, clean the Permanent Motor Protection Filter.

1

Remove the dustbag holder with the dustbag.

2

Take the Motor Protection Filter holder out of the appliance and clean the filter by shaking it
over a dustbin (fig. 27).

3

Press the filter holder with the clean filter firmly into place to ensure that it fits properly at
the bottom (fig. 28).

4

Place the dustbag holder with the dustbag back into the appliance.

Motor Outlet Filter

The AFS Micro Filter located in the back of this appliance will filter a large par t of the smallest
par ticles from the exhaust air by means of its electrostatically charged fibres.

1

Replace the AFS Micro Filter once a year.

2

Open the filter grille (fig. 29).

3

Remove the old filter (fig. 30).

4

Insert the new filter into the appliance.

5

Close the filter grille and push the left and right bottom corners until they click home (fig. 31).

Ordering accessories

If you have any difficulties obtaining dustbags, filters or other accessories for this appliance, please
contact the Philips Customer Care Centre in your countr y or consult the worldwide guarantee
leaflet.

Ordering dustbags

-

Philips S-bag paper dustbags are available under type number FC8021.

-

Philips cotton dustbags are available under number 432200493290.

Ordering filters

-

AFS Micro Filters are available under type number FC8030.

Ordering scent granules

-

Scent granules are available under type number FC8025.

E N G L I S H

9
