Telescopic tube with extension tube  (specific types only)

  1

 To connect the extension tube to the bottom part of the telescopic tube, insert the narrow

section into wider section and turn a little.

Note: To disconnect the tube parts from each other, pull and turn a little.

  2

  To connect the tube to the handgrip of the hose, insert the narrow section into the wider

section and turn a little (Fig. 6).

Note: To disconnect the tube from the handgrip, pull and turn a little.

  3

 To adjust the length of the tube to the length you find most comfortable during vacuuming,

press the button on the tube (1) and pull the upper tube part upwards or push it downwards

(2).  (Fig. 7)

nozzles
Connecting nozzles to the tube

  1

 To connect a nozzle to the tube, insert the tube into the nozzle and turn a little (Fig. 8).

Note: To disconnect a nozzle from the tube, pull and turn a little.

Combination nozzle with 1 rocker switch

You can use the combination nozzle on carpet (with the brush strips folded in) or on hard floors

(with the brush strips folded out).

 - To clean hard floors, push the rocker switch on top of the combination nozzle with your foot to

make the brush strips come out of the nozzle housing (Fig. 9).

 - To clean carpet, push the rocker switch to make the brush strips disappear into the

housing (Fig. 10).

super Parquet nozzle (specific types only)

You can use the parquet nozzle to clean parquet and other types of hard floors. The parquet nozzle

is equipped with rotating microfibre pads that gently clean and polish the floor and remove

stubborn dir t. The nozzle loosens dir t and traps it inside the fibres of the pads. The pads in

combination with the high suction power of this vacuum cleaner cause this nozzle to clean 3 times

better than ordinar y nozzles.

Never use water to clean wooden floors or parquet.

small nozzle and crevice/brush nozzle

  1

 Connect the small nozzle or crevice/brush nozzle directly to the handgrip or to the

tube (Fig. 11).

1

Small nozzle: use this nozzle to clean small areas, e.g. the seats of chairs and sofas.

2

Crevice/brush nozzle: use the crevice side of this nozzle to clean narrow corners or hard-to-

reach places and use the brush side to clean computers, bookshelves etc.

Using the appliance

Vacuum cleaning

 - You can carr y the vacuum cleaner by the handle at the front or on top of the appliance (Fig. 12).

  1

 Pull the mains cord out of the appliance and put the mains plug in the wall socket.

  2

 Press the on/off button on top of the appliance with your foot to switch on

the appliance (Fig. 13).

 - If you want to pause for a moment, inser t the ridge on the combination nozzle into the parking

slot to park the tube in a convenient position.  (Fig. 14)

English

8
