The dir t tray door closes automatically when you put the dir t tray back

into the sweeper base (‘click’).

Cleaning the roller brush

  1

 Switch off the appliance before you clean the roller brush.

 Remove the transparent front cover from the sweeper base. Grab

the bottom edge of the cover with both hands, pull it outwards (1)

and upwards (2) firmly until it is released from the slots (Fig. 16).

  Rotate the roller brush until the cutting groove faces you. Use a

pair of scissors to cut the hairs, threads etc that have collected

around the roller brush (Fig. 17).

 Remove fluff, hairs and other dirt from the roller brush.

removing the roller brush

  1

 To remove the stick, press the button on the lower handle (1) and

pull the stick upwards () (Fig. 5).

  Turn the sweeper base upside down, push the release slide in the

direction of the arrow (1) and remove the retainer (2) (Fig. 18).

 Slip the belt off the end of the roller brush (1) and lift the brush

out of the base () (Fig. 19).

 Remove fluff, hairs and other dirt from the roller brush and the

groove.

reinserting the roller brush

  1

 Slip the belt over the ribbed end of the roller brush. Insert the

other end of the roller brush into the slot opposite the

belt (Fig. 0).

  Insert the end of the roller brush with the belt into the other

slot.  (Fig. 1)

Do not force the roller brush into the slot. Rotate the roller brush so

that the ridge on the side with the belt points upwards.
