5

Filter and Cyclone Cleaning

Hold the cyclone in one hand, pinch the "UP" logo with the other hand, and take out filter (Figure 5).Do
Not tap the filter in reverse side in case of filter clog(Figure 6).

lean the cyclone metal filter with the attached mini brush(Figure 7).

After cleaning filter, remove the two screws on the cyclone cover with a screwdriver to separate
the cyclone cover from the cyclone to clean the internal air duct. After cleaning, assemble parts
in reverse order. (Figure 8).

After cleaning dust cup ,filter and cyclone, assemble in reverse order. Rotate the dust cup cover
assembly into the dust cup.After hearing a "click" and the dot mark is aligned with the lock
position that is assembled in place.

Notice:
1.Do Not miss the filter!
2.Use  water  or  neutral  reagents  to  clean  dust  cup  and  wipe  with  dry  cloths.  Do  not  wash  the  filter  until  it  is
necessary. Make sure the filter and dust cup are completely dry before another use.

 Figure 5

 Figure 8

 Figure 6

 Figure 7

Cyclone

MIF filter
