Hoover TSBE 2002 011 - Инструкция по эксплуатации - Страница 4

2

*  Certain models only

** May vary depending on model

GB

USING YOUR CLEANER

1.

Extract power cord and plug it into the power supply.

[5]

 Do not pull the cord beyond the

red marker.

2.

Adjust the telescopic tube* to the desired height by moving the telescopic tube adjuster up

and raise or lower the handle to the most comfortable cleaning position.

[6]

3.

Carpet & Floor Nozzle**. Press the floor type selector pedal on the nozzle

[7]

 to select the

ideal cleaning mode for the floor type.

hard Floor

  –  Brushes are lowered to protect the floor.

Carpet

  –  Brushes are raised for the deepest clean.

4.

Switch the cleaner on by pressing the On/Off button on the cleaner main body.

[8]

5.

Vary the suction as desired by closing or opening the suction regulator* on the hose

handle.

[9]

6.

Switch off at the end of use by pressing the On/Off button.

[8]

 Unplug and press the cord

rewind button to wind the power cord back into the cleaner.

[10]

7.

To store your cleaner, park the nozzle in the parking slot at the rear of the cleaner main

body.

[11]

ACCESSORIES

All accessories can be fitted to the hose handle or the end of the tubes.

2 in 1 Tool

 combines several functions into one tool:

Crevice Tool

 – For corners and hard to reach areas.

[12]

dusting Brush –

 For bookshelves, frames, keyboards and other delicate areas.

[13]

Pet hair Remover Mini Turbo Nozzle*

 - Use the mini turbo nozzle on stairs or for deep

cleaning on textile surfaces and other hard to clean areas. Particularly suitable for pet hairs

removal.

[1X]

Allergen Remover Mini Turbo Nozzle*

 – Use the mini turbo nozzle on stairs or for deep

cleaning on textile surfaces and other hard to clean areas. Particularly suitable for allergen

removal.

[1Y]

hard Floor Nozzle*

 – For parquet floors and other delicate floors.

[1Z]

IMPORTANT:

Do not use the Mini Turbo Nozzles on rugs with long fringes, animal hides and

carpet pile deeper than 15mm. Do not keep the nozzle stationary while the brush is rotating.

CLEANER MAINTENANCE

Emptying the dust Container

when the dust reaches the max level indicator on the container, empty the dust container.

IMPORTANT:

To maintain optimum performance, do not allow the dust to sit higher than the

max level.

1.

Release the dust container by sliding the dust container release button towards the front

of the cleaner. Lift the dust container from the cleaner main body.

 [14]

2.

Before emptying the Dust Container, gently tap it against the side of a bin to release any

excess dust from the filter.

3.

To empty the Dust Container, hold the Dust Container over a bin with one hand and use

the other hand to press the Dust Container Flap Opening Button to release the dust into

the bin.

[15]

4.

Close the Dust Container Flap and refit the Dust Container to the cleaner main body.

Cleaning the Washable Filters

The cleaner is fitted with a pre-motor and exhaust filter.  To maintain optimum cleaning

performance, regularly clean the filters. Remove excess dust from the filters by gently tapping

them against the side of a bin. The filters should be washed after every 5 container empties.

IMPORTANT: All bagless cleaners require regular filter cleaning. Failure to clean your

filters may result in air blockage, overheating and product failure. This may invalidate

your guarantee.

IMPORTANT: Regularly check and maintain the filters by following the filter maintenance

instructions, it is also recommended that you purchase new filters after every 3rd filter

wash. This will maintain your cleaners performance.

To access the pre-motor filter:

1.

Empty the Dust Container as described in ‘Emptying the Dust Container’. Then, keeping

the Dust Container Flap open:

2.

Remove the pre-motor filter by rotating it clockwise at the bottom of the Dust Container.

[16]

3.

Separate the protective mesh from the filter.

[17]

Gently tap both the protective mesh

and the filter against the side of a bin to remove excess dust and wash both of them

under warm water.

[18]

Do not use hot water or detergents.

4.

Remove excess water from the filter and leave it to dry fully before reusing.

[21]

5.

Once the filter is fully dry, reassemble the filter pack (protective mesh and filter) and refit

to cleaner.

6.

IMPORTANT:

 Do not use the product without the pre-motor filter pack fitted.

IMPORTANT:

Always ensure the filter packs are fully dry before use.
