GET TING TO KNOW YOUR CLEANER

ASSEMBLING YOUR  CLEANER

Remove all components from the packaging.

1.  Connect  the  hose  to  the  cleaner  main  body,  ensuring  it  clips  and  locks  into  position.

To release: simply press the button on the hose end and pull.

[1]

2.  Connect the hose handle to the upper end of the extension tube

[2]

, or accessories if required.

3.

Connect the lower end of the extension tube to the Carpet & Floor nozzle**

[3]

 or

accessories if required.

A.    Cord Reel Pedal
B.    Exhaust Filter Cover
C.    Exhaust Filter
D.    Parking Slot
E.    On/Off Pedal
F.    Dust Bin Release Button
G.    Dust Container Assembly
H.    Main Body
I.   Hose
J.    Suction Regulator
K.    Hose Handle
L.    Telescopic Tube
M.   Telescopic Tube  Adjuster
N.    Floor Type Selector Pedal*
O.  & O1. Carpet and Floor Nozzle

(GP)**

    O2. Carpet Nozzle

(CA)**

    O3. Hard Floor Nozzle

 (HF)**

P.   Dust container flap
Q.    Dust container flap release button
R.    Dust Container
S.    Multi-cyclone separation unit
T.    Pre-motor filter
U.    Dust container cover
V.    2 in 1 Accessory
W.   Pet Hair Remover Mini Turbo Nozzle*
X.    Allergen Remover Mini Turbo Nozzle*
Y.    Parquet Nozzle*

*Certain Models Only          ** Certain models only, nozzles may vary according to model

USING YOUR  CLEANER

ACCESSORIES AND NOZZLES

2

1.  Extract power cord and plug it into the power supply. Do not pull the cord beyond the

red marker.

 [4]

2.  Adjust the telescopic tube to the desired height by moving the telescopic tube adjuster

up and raise or lower the handle to the most comfortable cleaning position.

[5]

To obtain the best performance and  efficiency  it is recommended that the correct nozzles
are used for the main cleaning operations. These nozzles are indicated in the diagrams by
the letters

GP

,

HF

 or

CA

.

A nozzle type

GP

 can be used to clean both carpet and hard floor.

A nozzle type

HF

 is suitable for use only on hard floor.

A nozzle of type

CA

 is suitable for use only on carpet.

The other nozzles are accessories for specialist cleaning tasks and are recommended for
occasional use only.

All accessories can be fitted to the end of the hose handle or to the end of the telescopic tube.

2 in 1 tool

 – Combines several functions into one tool:

[V]

Dusting Brush

– For bookshelves, frames, keyboards and other delicate areas.

Crevice Tool

 – For corners and hard to reach areas.

Parquet Nozzle*

– For parquet floors and other delicate floors.

 [Y]

Pet Hair Remover Mini Turbo Nozzle

* - Use the mini turbo nozzle on stairs or for deep

cleaning on textile surfaces and other hard to clean areas. Particularly suitable for pet hairs

removal.

 [W]

3.  Carpet and Floor Nozzle** - Press the floor type selector on the nozzle

[6]

 to select the

ideal cleaning mode for the floor type.

Hard Floor

 – Brushes are lowered to protect the floor.

Carpet

 – Brushes are raised for deeper cleaning.

Carpet & Floor Nozzle**: [7]

-  Hard floors Cleaning:

 Press the pedal on the nozzle on Hard Floor mode and adjust the

slider on the nozzle on ALL FLOORS. In this position brushes, wheels and wiper blade

are lowered to protect hard floors.

[7a]

-  Standard Carpet & Rugs Cleaning:

Press the pedal on the nozzle on Carpet mode

and adjust the slider on the nozzle on ALL FLOORS. In this position brushes and wiper

blade are raised while wheels are lowered to allow a perfect ease of movement on such

surfaces.

[7b]

-  Deep Carpet Cleaning:

Press the pedal on the nozzle on Carpet mode and adjust the

slider on the nozzle on DEEP CARPET CLEANING. In this position brushes, wheels and

wiper blade are raised for a deeper cleaning of your carpet.

[7c]

WARNING: It is recommended to avoid potential scratching of wooden floors that

the pedal is not set on hard floor mode and the slider on deep carpet cleaning.

4.  Switch the cleaner on by pressing the on/off Pedal on the cleaner main body.

 [8]

5.  Adjust the suction regulator on the handle to the desired level.

[9]

6.  Switch off at the end of use by pressing the on/off Pedal. Unplug and press the cord

reel pedal to wind the power cord back into the cleaner.

[10]

PARKING AND STORAGE SECTION

The tube and the nozzle can be parked on the back of the cleaner for storage or temporary
storage while in use.

 [11]
