32
BS1306N_IM
02.11.17
• Use without brushes:
For vacuuming floor coverings
with a deep pile
• Use with brushes:
For vacuuming smooth floors
and carpets with a shallow pile
Crevice nozzle
With the crevice nozzle you can selectively vacuum corners
and slots.
Brush nozzle
The brush nozzle is especially suitable for vacuuming uphol-
stery, curtains, or books.
Assembly the Wall Holder
WARNING:
Make sure beforehand whether there are cables in the wall
which could be damaged!
1. Measure the height for the wall holder. Hold the vacuum
cleaner against the wall when it is fully assembled with
two suction tubes and the floor nozzle.
2. Hold the wall holder against the wall in a way that the two
drill holes are at the top. Mark 3 drill holes.
3. Drill the holes and insert the dowels into the wall.
4. Insert the screws through the holes of the wall holder.
Turn the screws with the wall holder into the dowels.
5. Tighten the screws by hand.
Using the Appliance
1. Unwind the power cord completely.
2. Insert the mains plug into a correctly installed power
socket.
3. Switch on the appliance with the on / off switch. Switch
position: “l”
4. Adjust the floor nozzle with the lever depending on the
floor covering.
5. Vacuum at a steady speed. There is no need to exert
pressure.
NOTE:
Pay attention to the range that can be covered with the
cable length!
End of Operation
1. Turn the vacuum cleaner off by the on / off switch and
remove the plug from the socket.
2. Let the device cool down completely.
3. If you have already installed the wall holder, hang up the
vacuum cleaner. You can attach the crevice nozzle and
the brush nozzle on the left and the right of the vacuum
cleaner.
4. You can wind the power cord loosely around the handle
and the dust collector.
Maintenance
Emptying the Dust Collector
1. Disconnect the mains plug from the wall socket.
2. If necessary, remove the suction tube or the nozzle
attachment from the appliance.
3. Hold the appliance with the bottom
plate of the dust collector over a
dustbin.
4. Empty the contents of the dust
collector. Slide the opener of the
dust collector downwards to open
the bottom plate.
5. Then close the base plate again. The lock on the dust
collector must engage.
The Filter System
Your appliance features 3 filters. The common dust bag
system has been replaced by a transparent dust collector.
The higher flow speed of the collector allows for heavy dirt
and smallest floating particles to be separated from the
“sucked-in air”.
It is thus not necessary to buy dust bags.
The filters must be cleaned periodically.
CAUTION:
• Never wash the filter in the washing machine.
• Do not use a hairdryer for drying.
• Put the appliance back into operation when all filters are
completely dry and correctly assembled.
The Filter Unit
The filter unit is composed of:
• HEPA filter
• Coarse filter
